Description
XXL End Ramp
Cable protector 5 channels | end piece with connector | heavy-duty design | height 8.7 cm
- Heavy-duty Cable protector made of black, recyclable polyurethane with integrated carrying handles for demanding applications
- Non-slip yellow polyurethane lid with high warning effect and secure locking mechanism
- Patented self-cleaning lid hinge
- 5 channels: 1 channel 60 x 63 mm, 2 channels each 61 x 59 mm and 62 x 65 mm
- Three channels suitable for C-hose couplings
- Load capacity approx. 5 tonnes / 25 x 30 cm
- Fire protection class B2 (DIN 4102)
- Resistant to oil, acid, petrol and short-term contact with solvents
- Reliable cable, hose and personal protection for indoor and outdoor use
- TÜV Süd certified
End piece with connector for DEFENDER XXL
Specifications
General
- Material TPU (Thermoplastic polyurethane)
- Surface structure Ribbed
- Colour Black
- Maximum load (on 25 x 30 cm) 5 t
- Chemical resistance Petrol, Solvents (short-term contact), Oil
- Hardness range (±4 Shore A) 88 Shore A
Shape
- Round Cable ducts
- Quantity 5
- Cable ducts size (W x H) 60 mm x 59 mm / 62 mm x 63 mm
Environmental
- Fire protection class (EN 13501-1) B2
- Ambient temperature -30 - 60 °C
Dimensions & weight
- Length 200 mm
- Width 696 mm
- Height 87 mm
- Weight 2.9 kg
