Description
L SUB 2000 – A LOW-END BOOST FOR THE LINEAR SERIES
Equipped with a sixth-order double bandpass crossover, the Linear SUB 2000 provides the perfect bass reinforcement for L5 mid/ high units. Its low-end performance in the 50-120 Hz range is most impressive. It sports two 12″ high-excursion woofers featuring a 2.5″ voice coil with a state-of-the-art cooling system and a dual spider suspension to keep it perfectly centered.
Features
- High-power system subwoofer for rental companies
- Power handling (continuous): 700 Watts (2800 W Peak)
- 2 x 12″ speakers with 2.5″ voice coil
- 133 dB Max SPL Peak @ 10% THD (halfspace)
- Rugged birch multiplex wooden enclosure
- Integrated HK Audio MultiGrip handles
- Ideal add-on to LINEAR 5 mid/high units
Specifications
- Power-handling nominal (RMS) 700 W
- Power-handling, program 1400 W
- Frequency response +/-3 dB 49 Hz – 125 Hz
- Frequency response -10 dB 39 Hz – 160 Hz
- Sensitivity 1 W @ 1 m 104 dB half space
- Max. SPL @ 10% THD 134 dB half space
- Max. SPL peak @ 10% THD 135 dB half space
- Electrical impedance 4 ohms
- Low-/mid speaker 2x 12", 2.5" voice coil featuring advanced cooling technology
- Crossover frequency controller driven
- Connections 2x Speakon NL4
- Integrated pole mount 1x M20
- Carrying handles 4x MultiGrip
- Housing Birch multiplex
- Finish Acrylic enamel, black
- Front grille 2 mm metal grille backed with black acoustic foam
- Dimensions (WxHxD) 50.6 x 80.6 x 61 cm 19-11/16 x 31-47/64 x 24-1/64"
- Weight 45.6 kg / 100.5 lbs
