Palmer Passive 2-Channel Line Splitter

(No reviews yet) Write a Review
SKU:
PAL-PPEENE
Weight:
1.80 LBS
Shipping:
Calculated at Checkout
  • Palmer Passive 2-Channel Line Splitter
  • Palmer Passive 2-Channel Line Splitter
  • Palmer Passive 2-Channel Line Splitter
$249.99

Description

RIVER peene
Passive 2-Channel Line Splitter

  • Distributes two input signals to two outputs each + link outs
  • For line signals
  • Galvanic isolation of outputs by transformers
  • Switchable ground lift to isolate ground loop hum
  • Neutral sound
  • High headroom (+20 dBu max. input level)
  • Passive construction, no power supply required
  • Extremely fail-safe
  • Solid casing made of aluminium and steel
  • Incl. rewritable tour label for attachment onto the back of the peene
  • Engineered in Germany

Do you want to send a line signal - stereo or dual mono - to multiple devices, without interference such as hum? Then the Palmer peene line splitter box is the right tool for you. It works on a purely passive basis with large isolation transformers, which can even handle high-level signals without distortion. So, for instance, you can send the stereo output signal from the mixer to several power amps, without any ground loops. The Palmer peene also includes a ground-lift switch. In addition to the two transformer-isolated outputs, the peene also directs the input signal on directly via a link out.

The Palmer peene is everything you need to distribute line signals to several devices and is a reliable audio tool with ultra-simple handling and professional sound characteristics.

View AllClose

Specifications

  • Product type Line Splitter
  • Channels 2
  • Type passive
  • Transformer isolated Yes
  • Number of inputs 2
  • input type balanced
  • Input connectors XLR
  • Number of outputs 4
  • Output type balanced
  • Output connectors XLR
  • THRU outputs per channel 1
  • Ground lift switch Yes
  • Housing Aluminium continuous casting
  • Dimension (H/W/D) 140 x 50 x 128 mm
  • Weight 0,805 kg
  • Ambient temperature during operation -20 - 70 °C
  • Relative Humidity < 80 %, not condensing
  • Accessories (included) Inscription label (tour label), rubber feet

Audio

  • Max. input level (< 1% THD, 20 Hz) + 20 dBu
  • Max. input level (< 1% THD, 1 kHz) + 32 dBu
  • Frequency response (±1 dB, relative 1 kHz) 10 Hz - 30 kHz
  • Input impedance (1 kHz) 6.8 kOhm
  • Output impedance (1 kHz) 500 Ohm(s)
  • THD (30 Hz, +4 dBu, unity, unweighted) < 1 %
  • THD (1 kHz, +4 dBu, unity, unweighted) < 0,02 %
  • IMD (SMPTE) (60 Hz / 7 kHz, 4:1, +4 dBu) < 0,01 %
  • Transformer ratio 1:1:1
