Description
Pedalbay® 60 PB
Pedalboard incl.WTPB60 Powerbar
The PEDALBAY® 60 PB set combines the Palmer PEDALBAY® 60 and the Palmer WT PB 60 power supply with 8 single-isolated outputs. Due to the patented integration, the power supply can be exchanged and fixed with the rear rail of the PEDALBAY® 60. A separate transport for power supply and PEDALBAY® is no longer necessary.
Specifications
- Product type Pedalboards
- Type Pedalboard with power supply unit
- Weight 4,48 kg
PPEDALBAY60 - Palmer Pedalbay® 60 PB Lightweight Variable Pedalboard with Protective Softcase, 60 cm
- Product type Pedalboards
- Material Aluminium
- Surface Powder-coated
- Width of the Cross Bars 50 mm
- Features Adjustable cross bars , Height-adjustable
- Weight Pedalbay 1.51 kg
- Width 605 mm
- Depth 305 mm
- Height 70 - 85 mm
- Weight 4,355 kg
- Accessories (included) 2x black elastic bands , allen key , approx. 3m hook tape , Soft carrying case with shoulder strap
PWTPB60 - Palmer Pedalbay® 60 PB Power Supply with 8 Outputs for PEDALBAY® 60
- Product type Power Supplies
- Mains connector Plug-in power supply
- Input voltage 100 - 250 V
- Outputs 8
- Output connectors 2.1 x 5.5 mm
- Material Aluminium
- Surface Anodized , Powder-coated
- Output voltage 12 V , 18 V , 9 V
- Max. output current 2 A
- Isolated outputs Yes
- Polarity Center negative
- Cord length 150 + 150 cm
- Indicators Fault , Power
- Controls Output voltage selector
- Width 600 mm
- Depth 50 mm
- Height 24 mm
- Weight 0,7 kg
- Accessories (included) 5x DC cable straight to angled 16cm long , 9x DC cable straight to angled 60cm long , hook-and-loop tape , M6 Nuts , M8 Nuts , Power supply
