Description
BiG
The Stereo Image Bigger Maker for series 500.
500 series double-slot module for stereo stage processing.
BiG is special.
BiG is unique.
BiG enlarges the stereo image in a new manner and opens up new creative ways of sound shaping.
Intuitive with just three controls.
On/Bypass
The On/Bypass switch activates (On) or deactivates (Bypass) the module.
This allows you to quickly switch between processed and unprocessed signal.
Signal LEDs
The signal LEDs (Sig) indicate whether an audio signal is present at the input of the respective channel.
(With a level higher than -20 dBu)
Stereo Image Shaping
- Range
- With the Range control, the frequency Range which should be processed can be selected.
- Stage
- With the Stage control, the frequency range previously selected with the Range control can be moved backwards or forwards on the stereo stage.
- BIGNESS
- The huge BIGNESS control adjusts the intensity of the STEREO IMAGE SHAPING.
BASS
The BASS/Off switch can be used to activate (BASS) or deactivate (Off) an additional bass boost following the BIGNESS section.
The bass boost is performed by a passive filter implemented in a similar circuit to the one used in the AirBass function of the SPL IRON Mastering Compressor.
Sounds good
With all SPL devices we develop not only according to plan, but also by ear.
All important components are installed on the circuit boards using Through-hole technology. This way we can ensure that we can use the best sounding components.
Home is where the heart is
That’s why we manufacture all devices in our own production facility in Niederkrüchten on the Lower Rhine, Germany.
Specifications
Input & Output; balanced
- Maximum input & output gain 21 dBu
- Input impedance 20 kΩ
- Output impedance 150 Ω
- Common mode rejection > 82 dB
- Frequency range (-3 dB) 10 Hz – 100kHz
- THD & N (0 dBu, 10 Hz – 22 kHz) 0.03 %
- Noise (A-weighted) -92.3 dBu
- Dynamic range 113 dB
Dimensions & Weight
Double-spaced module for 500 Series
- Unit weight
- 0.9 kg
- 1.98 lbs
- Shipping weight (incl. packaging)
- 1.05 kg
- 2.31 lbs
