Description
Delivering a full 500 Watts at 4 ohms, the ultra compact and lightweight Traynor SB500H is the ideal professional bass head for the musician on the move. Loaded with essential features including Active and Passive level instrument inputs XLR DI output, a versatile four band EQ with an additional low frequency expander, the SB500H allows virtually any tone to be dialed in quickly and easily.
The all-metal chassis with front mounted handles to protect the knobs and jacks ensures the SB500H is fully road ready. A rear mounted in-line effects loop, selectable Pre/Post EQ XLR DI output, front mounted tuner out (with mute) and heavy duty Speakon™ speaker outs are included.
The SB500H is made in Canada and like all Traynor products, covered by an unconditional two-year transferable warranty.
Key Features
- 500-watt Ultra Compact and Lightweight Bass Head
- Versatile 4-band EQ with Additional Low Frequency Expander
- All-Metal Chassis
- Active and Passive Inputs
- Selectable Pre / Post EQ XLR DI Output
- Rear Mounted In-Line Effects Loop
- Speakon™ Outputs
- Made in Canada
Specifications
- Power @ min. impedance (Watts) 500 watts
- Minimum Impedance (Ohms) 4
- Burst Power – 2 cycle 600 watts
- Inputs Passive 0 dB, Active -6 dB
- Controls Gain, Bass, Low Mid, High Mid, Treble, Low Expander, Master Volume
- Inline Effects Loop Yes – ¼-inch Send and Return- Rear
- Line Out (type / configuration) Balanced Pre/Post EQ Line Out W/ Ground Lift Switch
- Line Out Sensitivity (Vrms) 1 Vrms
- LED Indicators Blue – Power / Red – Protect/Mute
- Protection Clip, Thermal, Overcurrent
- External speaker output / location Speakon™ (x2 – Rear)
- Other Features Headphone Out /Mute / Tuner Out
- Dimensions (DWH, inches) 9.5 x 12 x 2.5
- Dimensions (DWH, cm) 22 x 30 x 6.5
- Weight (lbs / kg) 4.0 / 1.8
- Specifications subject to change without notice
