Vicoustic Trap Fuser Diffusion Panel - Black - Single Panel

(No reviews yet) Write a Review
SKU:
Trap Fuser
UPC:
5600301843099
Weight:
5.00 LBS
Shipping:
Calculated at Checkout
Availability:
Usually ships within 24 hours

Bulk discount rates

Below are the available bulk discount rates for each individual item when you purchase a certain amount

Buy 2 - 4 and pay only $90.00 each
$100.00

Description

Manufactured from high quality EPS (Expanded Polystyrene), the Trap Fuser is a unidirectional panel that controls sound reflections in two different ways - absorption and diffusion. Its hybrid structure allows sound energy to either be trapped in the cavities, or scattered by the plain surfaces. Usually applied for the treatment of mid or high frequencies, the Trap Fuser panel represents true acoustic science development.ï¾ Designed for a range of frequencies between 630 Hz to 5KHz.

In many practical applications, especially those that require a large area of diffusion treatment, it is common to repeat a same diffuser, so as to introduce periodicity into a sequence. This will concentrate the reflection energy in the diffraction orders of the grating and result in a narrower diffusion pattern. The innovation with the Trap Fuser lies in the freedom to position the panel's two halves and create random sequences. By rotating these diffusers in different directions, you can achieve combinations of patterns that are not only appealing to the eye but also extremely efficient when the aim is diffusing sound in a particular area. In fact, studies show that there are specific patterns that optimize diffusion and acoustic technicians can recommend which pattern works best, given the requirements of the area.

Assuming positions 0 and 1, the panels can be positioned according to simple binary sequences, with variations of 180°. Another possible combination is making 90° variations of the panels, thus transforming a one dimensional (1D) panel into a two dimensional (2D) system.

Features

  • Easy to install
  • Available in 3 colors: Black, White and Grey
  • Can be painted with water-based paints

Applications

Recording and Broadcast Studios, Post Production Studios, Listening Rooms, Conference and Teleconference Rooms, Lecture Halls, Distance Learning Rooms, Public Spaces, Auditoriums, Performance Spaces, etc.

View AllClose

Specifications

Dimensions: 595 x 590 x 169 mm
Scratch Resistance: No
Washable: No
Functionality: Diffusion
Absorption Frequency: Low Frequencies
alpha with Shape Indicators: 0.25
NRC: 0.350
Fire Class European (EN): Euroclass F
Material: Polystyrene
Polystyrene Density: 60.0
Edges: Angled
Installation Place: Wall , Ceiling
Fixing Type: Glued
