Description
ADAM SUB12
The Sub12 is a powerful subwoofer designed to extend the low frequency capabilities of any near or midfield monitoring system down to 22 Hz.
A sturdy special woofer with extended cone travel and a heavy-duty coil have been optimized for accurate reproduction from a bass reflex enclosure. The down-firing bass reflex tube avoids intrusive ventilation noise because of its generous size and shape. The PWM amplifier produces over 90% efficiency and can handle critical passages without overheating for long periods of time. An additional output allows you to cascade as many subwoofers as needed.
The Sub12 subwoofer provides a precise combination of low cutoff frequency (-3dB at 22Hz) and an undistorted high sound pressure level (115dB SPL at 1m).
- 12“ Subwoofer (paper)
- Amp. Power RMS / Music: 200 W / 300 W
- Frequency Response: 22 Hz - 150 Hz
- Max. peak SPL at 1 m: ≥115 db
Specifications
SUBWOOFER
Number: 1
Basket Ø: 12" (310 mm)
Voice Coil Ø: 2" (50 mm)
Cone Material: Paper
BUILT-IN AMPLIFIERS
Subwoofer: 1
Type: PWM
Amp. Power RMS / Music: 200 W / 300 W
INPUT CONNECTORS
Analog: XLR / RCA
GENERAL DATA
Frequency Response: 22 Hz - 150 Hz
THD > 60 Hz: ≤1 %
Max. peak SPL at 1 m: ≥115 dB
Crossover Frequencies: 50 - 150 Hz
Input Impedance: 10 kOhm
Panel: Rear
Weight: 57.3 lb (26 kg)
Height x Width x Depth: 23.5" (600 mm) x 14" (360 mm) x 17.5" (450 mm)
Warranty: 5 years (2 years warranty plus 3 years optional with product registration)
Delivery contents: Power cord, manual
