Description
The ATM650 is a dynamic microphone with a hypercardioid polar pattern. It is designed specifically for musical instrument pickup in the studio and
on stage. The hypercardioid polar pattern of the microphone is more sensitive to sound originating directly in front of the element, making it useful for controlling feedback and reducing pickup of unwanted sounds. The output of the microphone is a 3-pin XLRM-type connector.
The microphone is enclosed in a rugged housing with a multi-stage flat-grille design. The included AT8470 Quiet-Flex™ stand clamp permits mounting on any microphone stand with 5/8"-27 threads. A soft protective pouch is also included.
Features
- Tailored response for musical instrument pickup—guitar cabinets, snare and other per cussion
- Hi-ENERGY® neodymium magnet for improved output and transient response
- Special dual-wall floating construction reduces handling noise and assures consistent performance from mic to mic
- Hypercardioid polar pattern provides maximum feedback rejection and isolation of desired sound source
- Multi-stage flat-grille design is engineered to enable easy placement as close as possible to sound source
- Rugged all-metal design and construction for years of trouble-free use
- Corrosion-resistant contacts from gold-plated XLRM-type connector
- Quiet-Flex™ stand clamp provides silent, flexible microphone positioning
Specifications
POLAR PATTERN Hypercardioid
FREQUENCY RESPONSE 80-17,000 Hz
OPEN CIRCUIT SENSITIVITY –56 dB (1.5 mV) re 1V at 1 Pa
IMPEDANCE 300 ohms
WEIGHT 279 g (9.8 oz)
DIMENSIONS 164.2 mm (6.46") long, 38.8 mm (1.53") diameter
OUTPUT CONNECTOR Integral 3-pin XLRM-type
ACCESSORIES FURNISHED AT8470 Quiet-Flex™ stand clamp for 5/8"-27 threaded stands; 5/8"-27 to 3/8"-16 threaded adapter; soft protective pouch
AUDIO-TECHNICA CASE STYLE T5
