Description
Two-channel isolation transformer (line isolator). Neutrik combination socket input (XLR & jack socket) and XLR output. The PLI02 also has a ground-lift switch. Especially suitable for eliminating ground loops that cause hum. Conversion from unbalanced to balanced is possible. 600 ohm version can handle levels up to +20 dBu.
Professional dual channel line isolating unit for stage and studio use. A unique Neutrik input connector accepts both male XLR and jack plugs. The PLI-02 easily converts unbalanced outputs into balanced ones. It may also be used to transformer balance electronically balanced inputs and outputs.
Specifications
Product type: line isolator
Type: passive
Channels: 2
Inputs: 2
Input connectors: 6.3 mm Jack, XLR
Input type: balanced/unbalanced (depending on TS/TRS connection)
Input impedance: 0.6 k Ohm(s)
Max. input level: + 20 dBu
Outputs: 2
Output connectors: XLR
Output type: balanced/unbalanced (depending on TS/TRS connection)
Output impedance: 600 Ohm(s)
Max. output level: + 20 dBu
Transformer balanced: yes
Ratio: 1:1
Frequency response: 20 - 20,000 Hz
Controls: ground lift
Cabinet material: die-cast aluminium
Cabinet surface: powder coated
Width: 135 mm
Depth: 95 mm
Height: 35 mm
Weight: 0.53 kg
