Description
The 565SD microphone is a dual-impedance, unidirectional cardioid dynamic microphone with a strong, wire-mesh, spherical front grille that contains a highly effective wind and “pop” filter.
Shipped connected for low-impedance operation, a 565SD microphone provides excellent vocal or speech reproduction on stages and studios, and is a popular choice for use in public auditoriums, churches, convention halls, and schools.
Features
- Versatile, high-quality microphone with sound characteristics similar to the SM58
- Selectable dual-impedance operation
- Silent, lockable on/off switch
- Cardioid dynamic
- Frequency response: 50 to 15,000 Hz
Specifications
Type Dynamic (moving coil)
Frequency Response 50 to 15,000 Hz
Polar Pattern Cardioid
Output Impedance EIA rated at 150Ω (250Ω actual)
Sensitivity (at 1 kHz, open circuit voltage)
View AllClose
Frequency Response 50 to 15,000 Hz
Polar Pattern Cardioid
Output Impedance EIA rated at 150Ω (250Ω actual)
Sensitivity (at 1 kHz, open circuit voltage)
- L: −56.0 dBV/Pa (1.6 mV)
- H: −34.0 dBV/Pa (20 mV)
1 Pascal=94 dB SPL
Polarity Positive pressure on diaphragm produces positive voltage on pin 2 with respect to pin 3
Weight Net 0.298 kg (0.656 lbs)
Switch On/Off Lockable ON/OFF switch
Connector Three-pin professional audio (XLR), male
Case Chrome-plated die casting with steel mesh grille
