Description
The Studio Projects CS1 is an externally polarized cardioid pressure gradient transducer microphones with FET impedance converter. The capsule is a 1.06” (27mm) capsule, with a diaphragm thinkness of 6µm. It features four selectable pads, four high pass filters, and four low pass filters for added control in various recording applications and a clear, full response expected from a large capsule microphone design.
Versatility is key in the recording arena, and the Studio Projects CS1 is well equiped to handle any recording application. It is designed to deliver the finest quality vocal and instrumental recordings and will serve to enhance any professional or project studio.
As a result of uncompromising dedication and advanced production capabilities, Studio Projects will continue to broaden the range of quality pro audio microphones & electronics for today's recording environment.
Features
- Pressure-Gradient Transducer: 1.06" (27mm) 6um mylar diaphragm
- FET impedance converter
- -5dB, -10dB, -15dB, and -20dB Pads
- 50hZ, 75hZ, 150Hz, and 300hZ High Pass Filters @ 6dB/octave
- 15kHz, 7kHz, 5kHz, and 3kHz, Low Pass Filters @ 6dB/octave
Applications
- Close miking of instruments with high sound pressure levels
- Announcer's mic for broadcasting/dubbing
- Home recording and project studios
- Vocalist recording
- Spot mic for: wind instruments, strings, percussion and guitar amps
- XY - Coincident Cardioids
- Stereosonic Technique (2 mics required in Blumlein)
- Overheads
Included Accessories (In the CS1000 PAK)
- Shockmount
- Foam wind screen
- Pouch
- XLR Cable
Specifications
Type: Pressure gradient transducer microphone
Polar pattern: Cardioid
Frequency response: 20 - 20000Hz
Sensitivity: 14mV/Pa=-32dB(0dB=1V/Pa).
Output impedance: <200 Ohm
Load impedance: >1000 Ohm
Maximum SPL: 134 dB SPL for 1% THD @1000Hz (0dB SPL=0.00002Pa).
Noise: 10 dB-A (A-weighted per IEC268-15)
S/N: 84 dB-A
Pads: -5dB, -10dB, -15dB, and -20dB selectable
Low Pass: 15kHz, 7kHz, 5kHz, and 3kHz 6dB/Octave
High Pass: 50hZ, 75hZ, 150Hz, and 300hZ 6dB/Octave
Power requirement 48 +/- 4V
Current consumption: <4mA
Connector: Gold-plated 3-pin XLR
Circuit: JFET driven, discrete balanced output
