Description
RCA Right Angle Plugs
Switchcraft’s® right-angle RCA plugs (3502RA) features an easy-to-assemble three piece construction: a handle, insulator and plug assembly. The plug features a solid-pin design and large solder terminals that make termination faster and easier. The reduced profile makes it perfect for use behind equipment where space is at a premium. The larger cable clamp and handle will accommodate a variety of cable sizes. Available in nickel or gold-plated plug bodies with nickel or black finish handles, this new RCA plug will save time and space in any application.
Features & Benefits
- Solid center conductor
- High quality appearance
- Larger cable clamp provides better strain relief for large cables
- Longer cable clamp for easier plug assembly and more room for solder connection
- Knurl on the back of handle provides erognomic gripping surface to tighten plug
- Longer handle for improved gripping surface and easy plug withdrawal from jack
Specifications
Electrical
Contact Resistance (typical *D.O.M.J.): <0.20 ohms
Dielectric Withstand Voltage: 500VAC (minimum)
Insulation Resistance @ 500VDC: 2,000 megohms (minimum)
Insulation Resistance (after MIL-STD-202 Salt Spray): 1,000 megohms (minimum)
Working Voltage: 250VAC, 140VDC
Current Carry @ Working Voltage (typical *D.O.M.J.): 6.0 Amps
Mechanical
Insert/Withdrawal Force: Dependent On Mating Jack
Temperature Range: -40°C to +85°C
U.L. Component Recognition File No.: E118169
Life: Dependent On Mating Jack
Maximum Cable Size: .285” diameter
Material
Pin: Copper alloy, nickel-plated or gold-plated
Sleeve: Copper alloy, nickel-plated or gold-plated
Handle: Copper alloy, nickel-plated or black epoxy finished
Cable Clamp: C.R.S., electrotin-plated
Insulator: Rigid plastic
