Description
Synergy Rigging - SABUMPER1
Flying Array Bumper
The SABUMPER1 allows for fast and efficient rigging of the SA153 and SA315S cabinets.
This is a 4 wide column flying bumper which can safely handle two SA153 and one SA315S cabinets in each column for a 12 cabinet max hang at a safety factor of 7:1. Speaker cabinets are easily connected to the flying bumper using the same SALOCKBAR used for connecting cabinets to each other, no additional rigging accessories are required. Included with the SABUMPER1 are two extension tilt bars that can be used when extreme up tilt or down tilt are required. The extension bars are simply slid into the two central or the two outer main rails and secured in place with a 5/8" shackle (not included).
Specifications
- Max Load Capacity 2000lbs/907kg at 7:1 Safety Ratio
- Max Cabinet Capacity 4 column Wide Hang (Each Column = 2 x SA153 + 1 x SA315S Max. Total Cabinet hang = 12)
- Material / Construction 10 Gauge Welded Tube Steel
- Finish Black Powder Coat
- Included Accessories Two Extension Tilt Bars
- Required Shackle Size (Not Included) 5/8" (Sample Crosby#1018473)
- Overall Dimension DxWxH 26" x 59.5" x 4"
- Weight 64lbs with the extension bars, 55lbs without extension tilt bars
- Specifications subject to change without notice
