Description
The FUZE WASH Z120™ is a single source par moving head luminaire with a 120W Quad Color RGBW COB LED. Features 7° to 55° motorized zoom, pan and tilt, RGBW color mixing, electronic strobe and selectable dimming curve effects, DMX and RDM (remote device management) protocol support, DMX and power in/out connections, LCD menu display with 7 button control panel, multiple unit power linking, flicker free operation for TV and FILM, and a multi-voltage universal auto switching power supply (110-240v).
FEATURES
- 120W RGBW COB LED Moving Head Wash Luminaire
- RGBW Color Mixing
- 7° TO 55° Wide Motorized Zoom Range
- Variable Dimming Curves
- Multiple Unit Power Linking
- RDM (Remote Device Management)
- Flicker Free Operation for TV and FILM
Specifications
SOURCE
- 120W RGBW COB LED
- 100,000 Hour Average LED Life*
- *May vary depending on several factors including but not limited to:
- Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.
PHOTOMETRIC DATA
- 10,640 LUX 988 FC @9.8’ (3m) (7° Full ON)
- 692 LUX 64 FC @9.8’ (3m) (55° Full ON)
COLOR
- RGBW
EFFECTS
- RGBW Color Mixing
- 7° - 55° Beam Zoom Range
- Electronic Strobe, Dimming and Variable Dimming Curves
- 64 Color Presets and 14 Unique Color Macros
CONTROL / CONNECTIONS
- 4 DMX Channel Modes (19 Total Channels)
- 7 Button Control Panel and LCD Menu Display
- RDM (Remote Device Management)
- 3pin/5pin DMX and powerCON In/Out
SIZE / WEIGHT
- Length: 13.3" (338mm)
- Width: 9.0" (229mm)
- Vertical Height: 18.2" (466mm)
- Weight: 22 lbs. (10 kg)
ELECTRICAL / THERMAL
- AC 110-240V - 50/60Hz
- 157W Max Power Consumption
- Multiple Unit Power Linking
- 5°F to 113°F (-15°C to 45°C)
APPROVALS / RATINGS
- CE | IP30
