Description
The IP65 outdoor rated SIXPAR 300WMG HW includes the same features as the standard SIXPAR 300IP model but with a special added White Marine Grade exterior coating and Hard Wired (bare wire) IP-rated power/data combo in/out cables attached, designed for permanent marine/coastal environment installations.
Featuring (18) 12W 6-in-1 RGBAW+UV LEDs producing a 23° beam angle, internal color and color chase macros, electronic strobe and variable dimming curve modes, manual and DMX-512 control, RDM (remote device management) support, dual yoke / floor stand, rugged die-cast aluminum white marine grade coated exterior, flicker free operation for TV and FILM, and a multi-voltage universal auto switching power supply (110-250v).
Features
- P65 Outdoor Rated Par Luminaire
- Special White Marine Grade Exterior Coating
- Rugged Die-Cast Aluminum Exterior with Dual Yoke / Floor Stand
- (18) 12W 6-in-1 RGBAW+UV LEDs
- 23° Beam Angle
- 395nm UV Wavelength
- Electronic Strobe and Variable Dimming Curve Modes
- Manual and DMX-512 Control
- RDM (Remote Device Management) Support
- Hard Wired (Bare Wire) IP Rated Power/Data Combo In/Out Cables Attached
Specifications
SOURCE
- (18) 12W 6-in-1 RGBAW+UV LEDs
- 100,000 Hour Average LED Life*
*May vary depending on several factors including but not limited to:
Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.
PHOTOMETRIC DATA
- coming soon
EFFECTS
- Electronic Strobe
- Variable Dimming Curves Modes
- Internal Color and Color Chase Macros
CONTROL / CONNECTIONS
- Manual and DMX-512 Control
- (4) DMX Channel Modes (6 / 7 / 8 / 12)
- (4) Button Touch LCD Menu Display
- Hard Wired (Bare Wire) IP Rated Power/Data Combo In/Out Cables Attached
- With Wired Digital Communication Network
SIZE / WEIGHT
- Length: 14.4” (365mm)
- Width: 6.2” (157mm)
- Vertical Height: 14.4” (365mm)
- Weight: 19.2 lbs. (8.7 kg)
ELECTRICAL / THERMAL
- AC 110-250V - 50/60Hz
- 220W Max Power Consumption
- 5°F to 113°F (-15°C to 45°C)
- UV Wavelength: 395nm
APPROVALS / RATINGS
- CE | cETLus | IP65
Specifications and documentation subject to change without notice.
