Description
No more cables!
For houses of worship, hotels, clubs and band applications.
The PT45 is an analog high-performance wireless body-pack transmitter in a small, rugged housing. A professional mini XLR audio connector makes the body-pack compatible with all kinds of guitars, basses, instrumental pickups and headsets. It is designed for stress-free work on small stages, in houses of worship and in conference rooms.
The PT45 provides a gain control for perfect adjustment of the input volume and a noiseless on/off/mute switch. A battery-status indicator shows red before the battery goes dead, allowing the user full control of performance time. The package includes a rugged guitar cable.
Features
- Eight hours of operation from a single AA-size battery saves money in day-to-day use
- Professional three-pin mini XLR connector - compatible with guitar cables, headset and instrument mics
- Gain control on transmitter - for immediate volume adjustment
- Noiseless on/off/mute switch - for easy operation
- Compact and rugged body-pack design - for maximum wearing comfort
Specifications
Audio
Audio frequency bandwidth: 40 to 20000 Hz
Signal to Noise: 105 dB-A
THD at 1 kHz: 0.8 Prozent
Miscellaneous
Operating temperature range: -10 to 55 Celsius
Peak deviation: 45 kHz
Pocket Transmitter
Nominal deviation: 15 kHz kHz
Radio Output Power (min/max): 0 ... 0 mW
Transmitter Synchronization: Manual
Audio Input
Type: Mini XLR
Gender: Female
Contacts: 3-pin
Maximum audio level: 12 dB
Rated Impedance: 1 Ohms
Battery 1
Battery type: LR6 AA alkaline battery
Number of batteries: 1
Operating time: 8 h
Battery 2
Number of batteries: 1
Operating time: 8 h
Battery 3
Number of batteries: 1
Operating time: 14 h
Design
Body: Plastic
Finish: black
Dimensions / Weight
Length: 60 mm
Height: 75.5 mm
Width: 30 mm
Radio
Switching bandwidth: 30 MHz
Recommended simultaneous channels: 5
Number of selectable frequencies: 8 Fixed frequencies
Frequency Selection: Fixed frequency
Wireless channels within device -
Radio range (Line of sight): 30m
Switchable RF power: no
Modulation: FM
Encryption: No encryption
Pilot Tone: no
