Allen & Heath DX012 12 XLR Output Analogue/AES Portable DX Expander

(No reviews yet) Write a Review
SKU:
AH-DX012
Weight:
9.00 LBS
Shipping:
Calculated at Checkout
  • Allen & Heath DX012 12 XLR Output Analogue/AES Portable DX Expander
  • Allen & Heath DX012 12 XLR Output Analogue/AES Portable DX Expander
  • Allen & Heath DX012 12 XLR Output Analogue/AES Portable DX Expander
  • Allen & Heath DX012 12 XLR Output Analogue/AES Portable DX Expander
  • Allen & Heath DX012 12 XLR Output Analogue/AES Portable DX Expander
  • Allen & Heath DX012 12 XLR Output Analogue/AES Portable DX Expander
$1,499.00

Description

12 XLR Output Analogue/AES Portable DX Expander

Need to get more out of your system? DX012 provides remote output expansion for SQ, Avantis and dLive mixers, and for the AHM-64 audio matrix processor.

Perfect for feeding IEM systems and amplifier racks, DX012 offers both analogue and AES digital output options in a compact 1U form factor.

Each DX012 provides 12 XLR outputs, configurable as:

  • 12 analogue line outputs
  • 8 analogue line outputs + 4 stereo AES outputs
  • 4 analogue line outputs + 8 stereo AES outputs

The DX012 connects via a single Cat5e cable to the dLive Surface, dLive MixRack, AHM-64 matrix processor, Avantis mixer, SQ mixer or upstream DX expander via a secure EtherCon port.

A second locking EtherCon port is provided for redundant connection to compatible hardware, or for daisy-chaining to a downstream DX expander for additional remote I/O.

Features

  • Compatible with SQ, Avantis and dLive systems
  • 12 XLR Outputs:
    • 1-4 Analogue Line Out
    • 5-8 Analogue Line out or AES Digital out (switchable)
    • 9-12 Analogue Line out or AES Digital out (switchable)
  • AES outputs globally switchable between:
    • 44.1kHz
    • 48kHz
    • 88.2kHz
    • 96kHz
  • Cascade mode allows daisy-chaining of up to 2 DX Expanders on each DX port
  • Redundant DX connection to compatible hardware
  • Multiple DX012 can be added to a system:
    • Up to 16 DX012 units can be added to a SQ system
    • Up to 16 DX012 units can be added to an Avantis system
    • Up to 46 DX012 units can be added to a dLive S Class system
    • Up to 22 DX012 units can be added to a dLive C Class system
    • Up to 8 DX012 units can be added to an AHM-64 system
  • Rack-mounted (1u) or shelf/floor operation
  • Plug and Play – no IP addressing required
  • Compatible with CAT5e (or higher) cables of up to 100m
  • Locking EtherCon ports
View AllClose

Specifications

  • Digital Outputs AES3 2 Ch XLR, 2.5V balanced, terminated 110Ω
  • Sample Rate 44.1kHz, 48kHz, 88.2kHz, 96kHz
  • Analogue XLR Outputs Balanced, Relay protected
  • Output Impedance <60Ω
  • Nominal Output +4dBu = 0dB meter reading
  • Maximum Output Level +22dBu
  • Residual Output Noise -95dBu (22Hz-22kHz)
  • THD+N -98dB (0dBu, 1kHz)

Operating Temperature Range

  • 0°C to 40°C (32°F to 104°F)

Power

  • Mains Voltage Operating Range 100-240V AC, 50/60Hz
  • Mains Power Consumption 35W max

Dimensions and Weight

  • Width x Depth x Height x Weight
    • DX012 482.6 x 48.2 x 214.7 mm x 2.95kg
      • (19” x 1.9” x 8.5” x 6.5lbs)
    • DX012 (boxed) 600 x 335 x 150 mm x 4.1kg
      • (23.6” x 13.2” x 5.9” x 9lbs)
