Amphion Amp400 Multi-channel Amplifier

(No reviews yet) Write a Review
SKU:
Amp400.8
Weight:
16.00 LBS
Shipping:
Calculated at Checkout
  • Amphion Amp400 Multi-channel Amplifier
  • Amphion Amp400 Multi-channel Amplifier
  • Amphion Amp400 Multi-channel Amplifier
  • Amphion Amp400 Multi-channel Amplifier
$4,500.00

Description

Amp400

Wide variety configuration

Available in 8- and 12-channel versions, the Amp400 provides an exceptional level of multichannel amplification. As all channels are identical and discreet it can also be used in a 2-channel environment for driving up to 4 (Amp400.8) or 6 (Amp400.12) pairs of passive speakers.

Unique highlights

  • Low-distortion power
    • Amp400 delivers rock-solid control and tight, fast, highly resolving low-distortion power to get maximum performance from your monitors.
  • Added performance
    • To reach the needed sonic performance, a proprietary in-house designed buffer stage compliments the merits of the latest Class-D technology.
  • The perfect partner
    • Results-driven focus, careful sonic matching and quality components to make the amplifiers a perfect partner to all Amphion and other passive monitors.

Beautifully immersive

Immersive environment sets new demands for monitoring. Precise imaging, defined depth information and immaculate phase behaviour are a must when placing objects on the 3D-grid.

The Amp400.8

The Amp400.8 provides an exceptional level of multichannel amplification. It is built on the highly advanced Class-D platform, which offers abundant, fast, controlled, and low distortion power. To reach the needed sonic character and performance, an in-house designed buffer-stage was added to complement the merits of the latest Class-D technology. The buffer stage improves the impedance characteristics and cohesion between the channels, so that speed, control, neutrality, and ultra-low distortion can come across in an emotionally involving manner.

Though Amp400.8 was mainly developed for immersive audio, nothing prevents using it forother multichannel applications as well. As all 8 channels are identical and discreet it can also also be used in a 2-channel environment for driving up to 4 pairs of passive speakers. It will equally drive both 8 ohm and 4 ohm loads, and partners perfectly with all Amphion models. Though Amp400.8 was developed and optimized for Amphion monitors, it provides excellent results with wide range of passive speakers. Neutrik XLR and Speakon connectors offer a convenient and secure way to connect the amplifier to rest of the system.

The Amp400.12

The Amp400.12 provides an exceptional level of multichannel amplification. It is built on the highly advanced Class-D platform, which offers abundant, fast, controlled, and low distortion power. To reach the needed sonic character and performance, an in-house designed buffer-stage was added to complement the merits of the latest Class-D technology. The buffer stage improves the impedance characteristics and cohesion between the channels, so that speed, control, neutrality, and ultra-low distortion can come across in an emotionally involving manner.

Though Amp400.12 was mainly developed for immersive audio, nothing prevents using it for other multichannel applications as well. As all 12 channels are identical and discreet they can also used to power up to 6 stereo pairs of passive speakers. It will equally drive both 8 ohm and 4 ohm loads, and partners perfectly with all Amphion models. Though Amp400.12 was developed and optimized for Amphion monitors, it provides excellent results with wide range of passive speakers. Neutrik XLR and Speakon connectors offer a convenient and secure way to connect the amplifier to rest of the system.

View AllClose

Specifications

Amp400.8 Specs

  • Power rating
    • 410 W @ 1 % THD+N, 20 Hz – 20 kHz, 4 Ω (2 channel driven)
    • 205 W @ 1 % THD+N, 20 Hz – 20 kHz, 8 Ω (2 channel driven)
  • Dynamic range 121.5 dB(A)
  • Peak output current 20A
  • THD+N 0.001 % @ 10 W (4 Ω, 100 Hz) SE
  • Load independent frequency response 34 μV (A-weighted)
  • Minimum load impedance 3.5 Ω
  • Amp + power supply efficiency (max) >90 %
  • Mains Universal mains, auto select (100-240 V, 50-60 Hz)
  • Certification Safety EN/IEC/UL 62368-1 EMC EN/IEC 55032 (CISPR 32)
  • Inputs Balanced 3-pin XLR female
  • Speaker connectors Neutrik Speakon (NL2FX) 2-pole cable
  • Casing 19” rack mountable (3U), high quality aluminium
  • Power switch Back panel, rocker switch
  • Measurements (W x H x D) 483 x 133.3 x 317 mm (19” x 3½” x 12½”)
  • Weight 7.2 kg (16 lbs)

Amp400.12 Specs

  • Power rating
    • 410 W @ 1 % THD+N, 20 Hz – 20 kHz, 4 Ω (2 channel driven)
    • 205 W @ 1 % THD+N, 20 Hz – 20 kHz, 8 Ω (2 channel driven)
  • Dynamic range 121.5 dB(A)
  • Peak output current 20A
  • THD+N 0.001 % @ 10 W (4 Ω, 100 Hz) SE
  • Load independent frequency response 34 μV (A-weighted)
  • Minimum load impedance 3.5 Ω
  • Amp + power supply efficiency (max) >90 %
  • Mains Universal mains, auto select (100-240 V, 50-60 Hz)
  • Certification Safety EN/IEC/UL 62368-1 EMC EN/IEC 55032 (CISPR 32)
  • Inputs Balanced 3-pin XLR female
  • Speaker connectors Neutrik Speakon (NL2FX) 2-pole cable
  • Casing 19” rack mountable (3U), high quality aluminium
  • Power switch Back panel, rocker switch
  • Measurements (W x H x D) 483 mm x 133.3 mm x 317 mm (19” x 3½” x 12½”)
  • Weight 8 kg (17.7 lbs)
