Description
evo
START RECORDING BUNDLE
Start Recording...
Start your journey into the world of audio recording with the Start Recording Bundle, a professional, powerful and versatile solution for home recording. Experience a combination of outstanding audio performance and innovative technology to make sure you achieve studio quality recordings from the start.
What’s Included
- 1 x EVO 4
- Audio Interface
- EVO SR1
- Condenser Mic
- EVO SR2000
- Monitoring Headphones
- EVO
- Shockmount
- XLR
- Mic Cable
Evo 4
Audio Interface
Innovation at the core
Capture your microphones and instruments by recording audio directly to your computer with EVO 4’s intuitive feature set. Combining leading tech specs with astounding performance and sound quality, EVO 4 is the ultimate interface for beginners and pros alike.
EVO Mic Preamps
Building on Audient’s 20+ years of audio design experience, get unrivalled audio quality on your desktop with the clean, warm and accurate EVO preamps – offering 58dB of gain range.
Smartgain
Make sure you capture everything perfectly with Smartgain mode. Start playing, singing or talking and Smartgain will automatically set the level of your microphones. Perfect for beginners.
Audio Loop-back
Audio Loop-back enables you to record your computer audio at the same time as your microphones. Ideal for content creators, podcasters and streamers.
- Record your computers audio
- Record guest video calls
- Record gaming audio
Easy to set up
EVO 4 is USB 2.0 class compliant and works with both a USB-C and USB-A ports.
- USB-C to A Cable Included
- macOS Compatible
- Windows Compatible
Compatible with iOS devices and without the need for external power, EVO 4 truly lets you record anywhere.
SR1
A mic for moments
Capture every detail and nuance of your performance from the moment you hit record with the SR1 condenser microphone. Its large diaphragm design and versatile nature will give you studio quality recordings no matter the source.
SR2000
Its all in the details
The SR2000’s Monitoring Headphones not only deliver superior audio performance but have been engineered to provide long lasting comfort. The 40mm Neodymium drivers consistently deliver accuracy and clarity where you need it most, helping to make sure you make the right sonic decisions when recording and mixing.
Unlimited possibilities
Audio has no boundaries and neither should you. The Start Recording bundle provides the tools you need to get started, what you create is up to you.
Specifications
Microphone Preamplifier
- Mic Gain Range: 58dB
- Line Gain Range: 58dB (-10dB pad)
- Phantom Power: 48v +/-4v @ 10mA/Channel
- Mic EIN: <-128dBu
- CMRR: >85dB @ 1kHz
- Maximum Input Level: +16dBu
- Input Impedance (Mic): >3kΩ Balanced
- Input Impedance (Line): >10kΩ Balanced
- Frequency Response: +/-0.5dB 10Hz to 40kHz
- Crosstalk: <-105dBu @ 1kHz & 10kHz
- THD+N @ 0dBu (1kHz): <0.0015%
- SNR: 100dB
- XLR: Pin 2 (Hot), Pin 3 (Cold) & Pin 1 (Shield)
- 1/4” Jack: TIP (Hot), RING (Cold) & SLEEVE (Shield)
D.I
- D.I Gain Range: 58 dB
- Maximum Input Level: +10dBu
- Input Impedance: 1MegΩ Unbalanced
- Frequency Response +/-0.5dB 10Hz to 20kHz
- THD+N @ 0dBu (1kHz): <0.3%
- SNR: 100dB
- 1/4” Jack: TIP (Hot) & SLEEVE (Shield)
ADC Inputs
- Digital Reference Level: 0dBFS = +8dBu
- Frequency Response: +/-0.5dB 10Hz to Fs/2
- Crosstalk: -105dBu @ 1kHz & 10kHz
- THD+N @ -1dBFS (1kHz): <0.001%
- Dynamic Range: 113dB A-weighted
DAC Outputs
- Maximum Output Level: +11dBu
- Digital Reference Level: 0dBFS = +11dBu
- Output Impedance: <100Ω Balanced
- Frequency Response: +/-0.5dB 10Hz to Fs/2
- Crosstalk: <-110dBu @ 1kHz
- THD+N @ -1dBFS (1kHz): <0.0015%
- Dynamic Range: 113dB A-weighted
- 1/4” Jack: TIP (Hot), RING (Cold) & SLEEVE (Shield)
Headphone Output
- Output Impedance: <50Ω
- Frequency Response: +/-0.5dB 10Hz to Fs/2
- Crosstalk: -110dBu @ 1kHz
- THD+N @ -1dBFS (1kHz): <0.0015%
- Dynamic Range: 113dB A-weighted
- Max Level Into 30ohms: +0.5dBu, 0.0025% THD+N, 1.16Vpk Power: 45mW
- Max Level Into 60ohms: +4.22dBu, 0.0015% THD+N, 1.78Vpk Power: 52mW
- Max Level Into 600ohms: +10.1dBu, 0.0018% THD+N, 3.52Vpk Power: 20mW
- 1/4” Jack: TIP (Left), RING (Right) & SLEEVE (Shield)
DSP Mixer Roundtrip Latency:
(in to out)
- 44.1 kHz 0.594ms
- 48.0 kHz 0.552ms
- 88.2 kHz 0.302ms
- 96.0 kHz 0.281ms
DAW Playback Latency
@ 32 Sample Buffer for Software Instrument Playback
- 44.1 kHz ~2.5ms
- 96.0 kHz ~2ms
DAW Roundtrip Software Monitoring Latency
@ 32 Sample Buffer (in to out)
- 44.1 kHz 5ms
- 96.0 kHz 4.1ms
Latency – performance may vary as stability at these low buffer sizes is dependant on many factors including CPU load, operating system and performance of other drivers.
USB 2.0 High Speed
- No. Of Input Channels 2 Analogue
- No. Of Output Channels 2 Digital
- Connector: USB Type-C
- Included Cables: 1m USB 2.0 Type-C to USB Type-A
Weight & Dimensions
- Weights: Unit: 360g
- Packaged: 600g
- Dimensions: Unit: 140mm (w) x 67mm (h) x 67mm (d)
- Packaged: 172mm (w) x 88mm (h) x 97.5mm (d)
EVO SR1 Condenser Microphone
- Element 14mm back electronic condenser capsule
- Polar Pattern Uni-directional(Super-cardioid)
- Frequency Response 20Hz-18kHz
- Sensitivity 30dB±3dB (0dB=1V/Pa at 1kHz)
- Output Impedance 150Ω±30% (at 1kHz)
- Load Impedance ≥1000Ω
- Self Noise 16dB A
- Max. Input SPL 134dB (at 1kHz ≤1% T.H.D)
- S/N Ratio 78dB
- Phantom Power Requirement 5V or 48V
- Electrical Current 3mA
EVO SR2000 Monitoring Heaphones
- Operating Principle Closed
- Fashion Supra-aural
- Transducer Type Dynamic
- Loudhailer 40MM
- Impedance 32ohm
- Sensitivity/ Max. SPL 95±3dB/105±3dB
- THD <0.3%
- Frequency Response 15HZ-22KHZ
- Max. Power 400MW
- Rating Power 250MW
- Cable Type Straight
- Cable Length About 3M (straight)
- Plug 3.5MM+6.3MM
- Net Weight 233g(with cable)
- Norminal Headband Pressure Approx.2.8N
