Description
The U841R delivers exceptionally intelligible audio reproduction in a super-compact, low-profile design. Equipped with UniGuard® RFI-shielding technology, this omnidirectional condenser boundary microphone is designed for clear, highly intelligible sound quality in surface-mount applications. The phantom-powered U841R is equipped with self-contained electronics, eliminating the need for an external power module.
Features
- Designed for surface-mount applications where highly intelligible sound quality is required
- Small-diameter omnidirectional capsule near boundary eliminates phase distortion and delivers clear, high-output performance
- Superior off-axis rejection for maximum gain before feedback
- UniGuard® RFI-shielding technology offers outstanding rejection of radio frequency interference (RFI)
- Self-contained electronics eliminate need for external power module
- Heavy die-cast case and non-slip silicon foam bottom pads minimize coupling of surface vibration to the microphone
- Low-profile design with low-reflectance finish for minimum visibility
Specifications
| ELEMENT | Fixed-charge back plate, permanently polarized condenser |
| POLAR PATTERN | Omnidirectional in hemisphere above mounting surface |
| FREQUENCY RESPONSE | 40-20,000 Hz |
| LOW FREQUENCY ROLL-OFF | 80 Hz, 18 dB/octave |
| OPEN CIRCUIT SENSITIVITY | ̴̐35 dB (17.7 mV) re 1V at 1 Pa |
| IMPEDANCE | 200 ohms |
| MAXIMUM INPUT SOUND LEVEL | 130 dB, 1 kHz at 1% T.H.D. |
| DYNAMIC RANGE (typical) | 105 dB, 1 kHz at Max SPL |
| SIGNAL-TO-NOISE RATIO | 69 dB, 1 kHz at 1 Pa |
| PHANTOM POWER REQUIREMENTS | 11-52V DC, 2 mA typical |
| WEIGHT (MICROPHONE) | 84 g (3.0 oz) |
| DIMENSIONS (MICROPHONE) | 65.0 mm (2.56") diameter,
15.1 mm (0.59") maximum height |
| OUTPUT CONNECTOR | TB3M-type |
| CABLE | 7.6 m (25.0') long, 3.2 mm (0.13") diameter, 2-conductor, shielded cable with TA3F-type and XLRM-type connectors
|
| ACCESSORY FURNISHED | Soft protective pouch |
