Description
The SCX1-HC is a professional studio hypercardioid condenser microphone designed for a wide variety recording, broadcast and live sound applications. Known for its sensitivity, pin-point accuracy, low profile and consistency.
With a smooth uniform frequency response from 40 Hz - 20 kHz, the SCX1-HC is very consistent when responding to on and off-axis signals, and exhibits excellent phase coherence and minimal proximity effect. The SCX1-HC is characterized with a wide hypercardioid polar pattern; this, coupled with the high output and sensitivity of the microphone, makes the SCX1-HC an ideal choice for miking overhead, room ambience, orchestral sections, stringed instruments, piano, vibes and sound effects.
Other features include a 21 mm gold vapor capsule miniaturized electronics and an extremely small footprint. The SCX1-HC will handle sound pressure levels of 130 dB and will provide up to 20 dB of ambient noise rejection. In addition to acoustical instruments, the SCX1-HC is an excellent choice for group vocals, speech or Foley work.
The SCX1-HC, which is manufactured to exacting standards and tight tolerances, features a precision machined brass body, interchangeable capsules, black multilayer class ‘A’ liquid finish, laser etched model and serial number, Switchcraft® or Audix XLR connector and includes a heavy duty nylon clip.
Features
- Extremely sensitive, highly accurate
- Low noise electronics
- Small, low profile, easy to place
- Roadworthy
Applications
- Acoustic stringed instruments
- Ambient room miking
- Drum Overheads
- Studio Vocals
- Speech
- Piano, Vibes
- Flute, bells, chimes, marimba
- Audience mics for ear monitors
Supplied Accessories
- Foam lined wooden case (CASEWOOD)
- Heavy duty snap on nylon mic clip (DCLIP)
- External foam windscreen (WS81)
Specifications
Transducer Type Condenser
Frequency Response 40 Hz - 20 kHz
Polar Pattern Hypercardioid
Output Impedance 200 ohms
Sensitivity 15 mV / Pa @ 1k
Equivalent Noise Level 14 dB (A weighted)
Signal to Noise Ratio 80 dB
Maximum SPL 130 dB
Dynamic Range 116 dB
Power Requirements 48-52 volts
Connector Switchcraft® or Audix male XLR connector
Polarity Positive pressure on diaphragm produces positive voltage on pin 2 relative to pin 3 of output XLR connector
Housing / Finish Brass / Multi-layer Class ‘A’ liquid
Weight 114 g / 4 ounces
Length 104 mm / 4.1 inches
