Description
The TM1 is a 6 mm pre-polarized condenser microphone used for test and measurement applications. The TM1 is known for its linearity, accurate response, consistency, ease of use and affordability.
Equipped with a uniformly controlled omnidirectional polar pattern, the TM1 is designed to capture acoustic measurements for room analysis software programs, real time analyzers and other sound control devices. With a flat frequency range of 20 Hz – 25 kHz, the TM1 is an excellent tool for sound engineers, sound companies and recording enthusiasts.
The TM1 is designed, machined, assembled and tested by Audix in the USA.
Features
- 6mm pre-polarized condenser capsule
- Hi SPL response
- Precision machined brass housings
- Low noise electronics
- Replaceable electronics and capsule
- 3 year warranty
Applications
- Test and measurement
- Real time analyzers
- Room analysis software programs
- Ambient room miking
Supplied Accessories
- Heavy duty tension fit mic clip (DCLIP)
- Carrying pouch (P1)
Specifications
Transducer Type Pre-polarized Condenser
Frequency Response 20 Hz - 25 kHz +/-2dB
Polar Pattern Omni
Output Impedance 200 ohms
Nominal Sensitivity 6 mV / Pa @ 1k
Maximum SPL 130 dB with distortion < 1% 140 dB Max
Signal to Noise Ratio 66 dB
Equivalent Noise Level 28 dB (A weighted)
Dynamic Range 112 dB
Power Requirements 18-52 Volts phantom
Connector male XLR
Polarity Positive pressure on diaphragm produces positive voltage on pin 2 relative to pin 3 of output XLR connector
Housing 4 piece precision machined brass
Finish Nickel
Length 150 mm / 5.9 inches
