Description
The VX10 is a professional vocal condenser microphone designed to set new performance standards in the areas of live sound and broadcast applications. With a uniformly controlled frequency response from 40 Hz - 20 kHz, the VX10 is highly sensitive to transient response and will reproduce vocals and speech with exceptional detail and realism.
The VX10 is characterized with a cardioid polar pattern which helps isolate the vocals from the rest of the instruments on stage. Other features include a 21 mm gold vapor capsule and a multi-stage internal pop filter. The VX10 will handle sound pressure levels of ≥138 dB and will provide over 20 dB of ambient noise rejection on live stages.
In addition to vocal applications, the VX10 is ideally suited to capture acoustic instruments such as guitar, woodwinds, brass, percussion toys, drum overheads, hi-hat and piano. It is an excellent choice for professional studio recording.
The VX10 is well balanced, comfortable to hold, durable, and manufactured with high standards and tight tolerances. The VX10 includes a precision die cast zinc alloy body, black E-coat finish, laser etched model and serial number, Switchcraft® or Audix XLR connector and heavy duty nylon clip.
Audix VX10-Lo Vocal Condenser Microphone
The VX10 is also available in a low output model (VX10-Lo) for greater control with loud stage volumes or extremely powerful vocalists. It is suitable for high SPL applications and close proximity vocals. The VX10-Lo has -18dB lower output.
Features
- Studio quality sound
- Extremely detailed and accurate
- Multi-stage internal pop filter
- Low noise circuitry
- Comfortable to hold
- 3 year warranty
Applications
- Lead vocals
- Background vocals
- Studio vocals
- Speech
- On air announce microphone
- Live performance and live broadcasts
- Excellent for use with in-ear monitors
- Acoustic instruments
Supplied Accessories
- Foam lined wooden carrying case (CASE WOOD)
- Heavy duty nylon mic clip (MC1)
- Carrying pouch (P1)
*The product requires 48-50V phantom power supply (APS-2), which can be ordered separately.
Specifications
Transducer Type Condenser
Frequency Response 40 Hz - 20 kHz
Polar Pattern Cardioid
Output Impedance 250 ohms
VX10 Sensitivity - 24 mV / Pa @ 1k
VX10-Lo Sensitivity - 4 mV / Pa @ 1k
Equivalent Noise Level 19 dB (A weighted)
Signal to Noise Ratio 75 dB
VX10 Off Axis Rejection >20 dB
Maximum SPL ≥138 dB
Dynamic Range 119 dB
Power Requirements 48 - 52v phantom
Connector Switchcraft® or Audix male / XLR connector
Polarity Positive voltage on pin 2 relative to pin 3 of output XLR connector
Housing / Finish Die Cast Zinc Brass capsule housing/ Black E-coat
Weight 318.6 g / 11.24 ounces
Length 180 mm / 7.1 inches
