Auvitran AxC-AS8M v2 High density Mic/Line card with 8 In on DB-25

(No reviews yet) Write a Review
SKU:
AxC-AS8M v2
UPC:
641094923280
Weight:
100.00 LBS
Shipping:
Calculated at Checkout
  • Auvitran AxC-AS8M v2 High density Mic/Line card with 8 In on DB-25
  • Auvitran AxC-AS8M v2 High density Mic/Line card with 8 In on DB-25
$1,399.00

Description

Like all other cards within the Audio ToolBox range, the AxC-AS8M can be used in either the AVBx3 or AVBx7 platforms.

Using only one slot of the Audio ToolBox, the AxC-AS8M provides 8 high-end Mic/Line input (both line and microphone level) with an incredible density for the AuviTran Audio ToolBox platform.

Key Features

  • 8 microphone/line high density inputs card
  • 8 balanced mic/line + high quality preamps
    • Input sensibility +24dBu to -56dBu
    • Analog gain range: 0 to +80dB (0.5dB step)
    • E.I.N. < -126dBu
    • Dynamic range > 115dB (Aw)
    • THD+N < -90 dB
  • Phantom power +48V, individually controllable for each input
  • 1 DB25 female connectors
  • Remote management using AVS-Monitor via IP, Dante, AVB or EtherSound Network.
  • Dedicated control page for monitoring and controlling all the card parameters (gain, phantom power on each channel, preamp values, vu-meter)

Mechanical Specifications

200 x 100 x 40 mm: AuviTran Audio ToolBox platform AxC card format

AxC-AS8M Applications

Suitable for all professional applications that request large numbers of high-quality Mic/Line inputs with a reduced size:

  • Featuring 8 high performance microphones and line pre-amplification, high class AD converter chips and excellent circuit design
  • AxC-AS8M card sets a new quality, price, density ratio standards for professional audio applications.
  • A linear 0.5 dB step digital attenuator/gain gives access to an input sensibility from -56dBu to +24dBu.
  • +48V phantom power activation per channel, preamp value setting,
  • Attenuation/gain settings and vu-meter can be controlled and monitored individually per channel via network for a remote management from virtually anywhere.
  • All individual gains and +48V phantom power activation remote controls are manageable by Yamaha HA remote protocol enabling direct control and monitoring from Yamaha console/mixer

Audio ToolBox Platform Overview

Smart, expandable and sustainable: meet AuviTran’s versatile and flexible platforms that brings convergence among network technologies and audio interfaces.

With two 19” rack chassis AVBx3 and AVBx7 both available in StageBox or Installation modes, plus 20 interface cards, build the configuration you need.

View AllClose

Specifications

General

  • Size 200 mm x 100 mm x 40 mm –AuviTran Audio ToolBox platform cards format
  • Power Supply +12V / +3.3V - Through AuviTran Audio ToolBox backplane
  • Storage: Temp / Humidity -5°C to 70°C / 0% to 95% (non-condensing)
  • Operating: Temp / Humidity 0°C to 50°C / 5% to 90% (non-condensing)
  • Connectors
    • 1x female DB25 connectors (Yamaha pinout)
    • Optional: DB25 to EuroBlock plug available

Audio Inputs

  • Number of inputs 8 Mic/line inputs

Audio Inputs Specifications

  • Sampling Frequency 44.1kHz, 48kHz, 88.2kHz or 96kHz
  • ADC resolution 24 bits
  • Input specification Balanced Mic/line
  • Input maximum level +24 dBu

Audio Inputs MIC / Line Technical Specifications

  • Analog Gain Range 0dB to +80dB (0.5 dB step)
  • Input sensibility +24dBu to -56dBu
  • Input Impedance 2,7 kΩ (differential)
  • E.I.N. @ (Rs=150Ω G=+80dB) -126dBu
  • Dynamic Range > 115dB A-weighted (> 112dB un-weighted)
  • THD+N (1KHz) < -90 dB
  • Frequency response 20Hz – 20kHz +/- 0.2dB)
  • Phantom Power +48 V (individually controllable for each channel)

Integration Environment

  • Audio ToolBox platform AxC-AS8M is one the cards for the AuviTran Audio ToolBox platform
  • AVS-Monitor AVS-Monitor enables to remotely set, control and monitor an IP, Dante, AVB network and provides enhanced control pages to manage the AxC-AS8M card specific parameters.
  • OS Supported Windows 10 for 32-64-bit versions
