Connections

• SDI Video Inputs 1 x SD, HD or 3G-SDI.
• SDI Video Outputs 1 x SDI loop out.
• HDMI Outputs HDMI Type A out.
• Multi Rate Support Auto detection of SD or HD.
• Updates, Configurations and Power USB Type‑C

Standards

• SDI Video Standards
• 525i59.94 NTSC, 625i50 PAL
• HD Video Standards
• 720p50, 720p59.94, 720p60
• 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p47.95, 1080p48, 1080p50, 1080p59.94, 1080p60
• 1080PsF25, 1080PsF29.97, 1080PsF30
• 1080i50, 1080i59.94, 1080i60
• 2Kp23.98 DCI, 2Kp24 DCI, 2Kp25 DCI, 2Kp29.97 DCI, 2Kp30 DCI, 2Kp47.95 DCI, 2Kp48 DCI, 2Kp50 DCI, 2Kp59.94 DCI, 2Kp60 DCI
• 2KPsF25 DCI, 2KPsF29.97 DCI, 2KPsF30 DCI
• SDI Compliance
• SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 424M, SMPTE 425M
• SDI Video Rates
• SDI video connections are switchable between standard definition, 720p 1080i, 1080p, and DCI high definition.
• SDI Color Precision
• 4:2:2
• SDI Color Space
• YUV
• SDI Auto Switching
• Automatically detects SD, HD and level A or B for 3G‑SDI.
• HDMI Video Standards
• 525i29.97 NTSC, 625i25 PAL
• 720p50, 720p59.94, 720p60
• 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p47.95, 1080p48, 1080p50, 1080p59.94, 1080p60
• 1080i50, 1080i59.94, 1080i60
• HDMI Color Precision
• 4:2:2. A 17 point LUT can be loaded via the software utility for calibrating or improving monitor color.
• HDMI Color Space
• YUV

Software

• Software Control
• Mac OS X™ and Windows™ software upgrade via USB.
• Internal Software Upgrade
• Via USB.

Operating Systems

• Mac 10.14 Mojave, Mac 10.15 Catalina or later.
• Windows 10.

Settings Control

• Via software utility.

Power Requirements

• Power Consumption 1.60 Watts
• Operational Voltage Range 4.4V to 5.25V DC

Environmental Specifications

• Operating temperature
• 0° to 40° C (32° to 104° F)
• Storage temperature
• -20° to 60° C (-4° to 140° F)
• Relative Humidity
• 0% to 90% non-condensing

What's Included

• Micro Converter SDI to HDMI

Warranty

• 3 Year Limited Manufacturer's Warranty
