Description
The BLU-USB allows audio from a PC/Mac to be directly placed onto the BLU link audio bus, enabling easy implementation of softphones for conferencing systems or audio playback directly to/from a computer.
Features
- Simple integration of computers to Harman audio systems
- Digital conversion directly to BLU link
- Eliminates USB Distance Limitations
- Multiple mounting options
Specifications
No driver installed (Class 1)
- 2 x 2 plug 'n' play operation
- 48kHz
Driver installed (Class 2)
- 8 x 8 operation
- 48/96kHz
COMPUTER AUDIO PLAYBACK
- Supported Sound File Sample Rates: 8kHz–192kHz
- Supported Sound File Bit Depths: 16-bit, 24-bit (24-bit recommended for best performance)
- Supported Drivers: Windows: WDM, ASIO, Mac: Core Audio
BLU LINK BUS
- Supported Sample Rates: 48kHz, 96kHz (compatible with Class 2 USB mode only)
- Connectors: 2 x RJ45 Ethernet connector
- Maximum Cable Length: 100m/328ft on Category 5e cable between devices
- Pass-Through Latency: 4/Fs [0.08ms at 48kHz, 0.04ms at 96kHz]
- Maximum Nodes: 60
POWER/TEMPERATURE
- Mains Voltage: 100-240V AC, 50/60Hz
- Power Consumption: 4 Watts
- Operating Temperature Range: 5 [41] to 35 [95] degrees C [degrees F]
PHYSICAL
- Weight: 1 lb./ 0.45 kg
- Dimensions: 3.85" (W) x 1.57" (H) x 5.67" (D)/ 97.8 mm (W) x 39.9 mm (H) x 144.0 mm (D)
