Description
PFPower's BATT1500-EXT Battery Pack offers extended run-time for the F1500-UPS.
This 2RU battery pack aesthetically matches the F1500-UPS and can be rack or tower mounted. The heavy gauge power cord is adapted with plug-n-play DC connectors for easy installation. The all metal enclosure safely houses the 8 (eight) 12V 9Ah batteries which are connected via 2 strings of 4 in serial.
Features
- Extend Runtime — Extends battery runtime of Furman's F1500-UPS by up to 4x
- Form Factor — 2U configuration supports both rack and tower mounting
- Metal Housing — Rigid metal construction allows for placement in areas with a demanding environment
- Power On/Off Switch — Local power switch for manual reset & control
- Back-panel Fuse — User replaceable fuse which is easily accessed from the rear panel
Specifications
Battery
Battery Type Sealed lead acid
Battery Size 12V/9AH
User Replaceable Yes
Hot Swappable Yes
Typical Recharge Time 8 hours
Replacement Battery BB Battery - HR9-12
Battery Quantity 8
Environmental
Operating Temperature 32°F to 95°F / 0°C to 40°C
Operating Humidity 0% - 95% non-condensing
Maximum Operating Elevation 10,000 ft / 3,000 m
Storage Temperature 5°F to 113°F / 15°C to 45°C
Maximum Storage Elevation 50,000 ft. / 15,000 m
General
Dimensions 19”W x 17”D x 4”H
Weight 67 lbs.
Certifications UL1778, cUL 107.1, FCC DOC Class B
ROHS ROHS Compliant
Rack Size 2RU
