Description
12" High Power Cinema Surround For Multi Channel Applications For Multi Channel Applications
The 9320 Cinema Surround Speaker offers very high power handling, high sensitivity, and extended bass response. The two-way 9320's performance features position it as the ideal high power surround for multi-channel surround applications.
Features
- 35 Hz to 20 kHz Frequency Range
- High Sensitivity, 98 dB SPL, 1 w, 1 m (3.3 ft)
- High Power Handling Capability. 400 watts continuous pink noise
- Multiple M-10 threaded mounting points
- 120° x 60° Coverage
- Multi-ply birch enclosure
- Progressive Transition high frequency waveguide
- Input terminals located on top of cabinet for easy access
Specifications
- Frequency Range (-10 dB) 35 Hz-20 kHz
- Frequency Response (±3 dB) 50 Hz-19 kHz
- Power Rating 400 Watts continuous pink noise, 1600 Watts peak
- Sensitivity (1W/1m) 98 dB-SPL half space/ wall mounted
- Maximum Peak SPL 124 dB/1m
- Nominal Impedance 8 ohms
- Hor. Coverage Angle (-6 dB) 120° averaged 2 kHz to 10 kHz
- Vert. Coverage Angle (-6 dB) 60° averaged 2 kHz to 10 kHz
- Directivity Factor (Q) 6.3 averaged 800 Hz to 10 kHz
- Directivity Index (DI) 8.4 dB averaged 800 Hz to 10 kHz
- Crossover Frequency 1.9 kHz
- Polarity EIA (Positive voltage to RED terminal gives forward cone motion)
- Low Freq Transducer Nominal 300 mm (12")
- High Freq Transducer Nominal 38 mm (1.5" voice coil)
- Downward Firing Angle Nominal 15° when mounted flush on wall
- Enclosure Material Birch multi-ply
- Grille Color Black
- Input Connectors NL4 Neutric Speakon and barrier strip
- Dimensions (H x W x D)
- 638.3 mm x 368.3 mm x 416.6 mm
- 26.9 in x 14.5 in x 16.4 in
- Net Weight 17.5 kg (38.5 lbs)
