Description
Two-Way Full-Range Loudspeaker System with 1 x 15" LF
AC566 is a compact 2-way full-range loudspeaker system comprised of one 384 mm (15 in) low frequency driver and one 25 mm (1 in) exit/35 mm (1.5 in) voice-coil compression driver. The horn provides 60° by 60° coverage in vertical and horizontal orientation. High-slope passive crossovers minimize band overlap and well-controlled offaxis response. The cabinet is fitted with M10 threaded suspension points. Four threaded inserts located on back of the enclosure allow attachment of an MultiMount® or similar type mounting. AC566 is part of JBL's AE Application Engineered Series, a versatile family of loudspeakers for a wide variety of fixed installation applications
FEATURES
- Robust 15mm enclosure with black textured finish
- 384 mm (15 in) LF transducer
- 60° x 60° Waveguide with a 25 mm (1 in) exit 35mm (1.5") diaphragm compression driver
- Dual Neutrik NL4 connectors plus screw terminals
- Multiple attachment points for ultimate flexibility
APPLICATIONS
- Performing Spaces
- Clubs & Bars
- Houses of Worship
- Multi Media Spaces
- Retail & Hospitality Spaces
- Presentation Suites
- Educational Facilities
Specifications
- Frequency Range (-10 dB) 60 Hz - 20 kHz
- Frequency Response (±3 dB) 75 Hz - 18 kHz
- System Sensitivity (1w @ 1m) 98 dB
- Nominal Impedance 8 ohms
- Maximum SPL (1m) 122 dB (128 dB peak)
- Power Rating (Continuous/Program/Peak) 250 W/500 W/1000 W
- Coverage Pattern 60° x 60° (H x V)
- Crossover 1.5 kHz
- Low Frequency Driver 1 x 15" woofer (P/N: 5053935), 384 mm (15 in) driver with 66 mm (2.5 in) voice-coil
- High Frequency Driver 1 x 2408H-2 driver with 25 mm (1 in) exit/38 mm (1.5 in) voice-coil
- Input Connector Dual Neutrik NL4MP connectors plus covered barrier trip terminals
- Enclosure 15 mm multi-ply hardwood plywood
- Grille Powder coated, 1.5mm perforated steel, with acoustically transparent black foam backing
- Finish Textured black paint finish. White (-WH) available upon request. Not available with WRC & WRX finish.
- Suspension / Mounting 14 x M10 and 4 x M10 for Wall Mount Bracket. Optional U-bracket, L-bracket and wall-mount bracket
- Dimensions (H x W x D) 680 mm x 420 mm x 445 mm / 26.7 in x 16.5 in x 17.5 in
- Net Weight 19.8 kg (43.6lbs)
