Description
Background/ Foreground Ceiling Loudspeakers
The Control 24C is a compact in-ceiling speakers, providing full, high quality sound for background music and music-plus-paging systems.
- Features
- Coaxially mounted 100 mm (4 in) woofer with butyl rubber surround and 19 mm (.75 in) titanium coated diffraction-loaded tweeter.
- High power, wide frequency response and low distortion for high sound level capability.
- Wide coverage allows fewer speakers, reducing the cost of the installed sound system without sacrificing performance.
- JBL’s exclusive SonicGuard™ overload protection allows higher operational levels and improved system reliability.
- Packaged with grille, backcan and tile rails for fast installation and easy dealer stocking.
- Sold in pairs
Specifications
Frequency Range: 80 Hz - 20 kHz
Power Capacity: 80 W Continuous Program Power; 40 W Continuous Pink Noise
Nominal Sensitivity: 86 dB SPL @ 1 m (3.3 ft)
Nominal Coverage Angle: 130° conical coverage
Directivity Factor (Q): 2.4 dB averaged 500 Hz to 4 kHz
Directivity Index (DI): 3.8 dB averaged 500 Hz to 4 kHz
Rated Maximum SPL: 102 dB @ 1 m (3.3 ft)
Nominal Impedance: 16 ohms (Min Z 16.1 ohms @ 320 Hz) (24C)
