Description
Model C2PM
Perfect for a range of professional applications including:
- Recording / Video Production
- Entertainment Installations
- AV Presentations
- Monitoring of Electronic Musical Instruments
Features
- Studio quality transducers for accuracy, and rich bass response: 80 Hz - 20 kHz
- 35 watt power amplifier and high sensitivity drivers produce exceptional output: 111 dB peak SPL
- Balanced XLR, ¼”, and unbalanced RCAinputs allow connection to a range of signal sources
- Stereo headphone jack allows monitoring using headphones
- Ergonomic, side-mounted volume control
- High frequency adjust control - allows the user to contour HF response to application requirements
- Magnetically-shielded transducers for use near CRT monitors and magnetically sensitive equipment
- Internal peak limiter and overload protection circuit - protects the system from damage caused by continuous over-driving
- Wall-mount capable using optional MTC-2P mounting kit
- Included snap-on pedestal to optimize listening angle for desktop applications
Specifications
Transducers LF: 135 mm (5.25 in) low frequency loudspeaker
HF: 19 mm (.75 in) Polycarbonate dome tweeter
Frequency Range: 80 Hz - 20 kHz
Amplifier Power: 35 Watts
Maximum SPL: 111 dB
Crossover Frequency: 4.2 kHz
Input Sensitivity: +4 dBu XLR 1/4"; 0 dBu RCA
Signal Input Connectors: (x2) Balanced Neutrik®* Combo XLR 1/4" TRS; Unbalanced RCA
Power Requirements: 19 VDC / 3.42 A - use only supplied power supply
Headphone Jack: 3.5 mm (1/8")
Dimensions: 235 x 159 x 143 mm (9.3 x 6.3 x 5.6 in)
Net Weight: 2.6 kg (5.5 lb)
