Description
Everything You Need to Be Heard
Get legendary sound quality with the EON208P all-in-one portable PA system, complete with an 8-channel mixer and Bluetooth audio. With a convenient suitcase-style design, the EON208P makes it easy to get great sound for performances, meetings and events. The 8-channel detachable mixer provides professional connections for mics, instruments and line-level sources, while the 8” two-way stereo speakers deliver best-in-class audience coverage. Bluetooth connectivity also allows you to stream audio from your mobile device. With 300 watts, you’ll have more than enough volume to be heard. Plus, the compact and lightweight form factor means you can carry the entire system with one hand.
Professional-Grade Mixer
The 8-channel detachable mixer gives you the power and flexibility to sculpt your sound and be heard with stunning clarity at any venue. Simply connect your mics, instruments and other sound sources and start performing. The intuitive mixer helps you dial-in great live sound quickly and easily.
Bluetooth Streaming
With Bluetooth connectivity, EON208P lets you stream audio from your mobile device. Now you can DJ a party right from the dance floor, or play pre-recorded material for your meeting, worship event, or health club—all without the hassle of wires.
Portable Design
EON208P puts professional audio within arm's reach—literally. The twin 8” speakers and 8-channel mixer clip together to form the most comprehensive, lightweight and portable PA in its class. Carry it in one hand with a guitar slung over your shoulder to play coffee shops and medium-size gigs. Or turn a backyard into the hottest nightclub around. With uncompromising JBL sound quality and effortless portability, you’ll want to take it everywhere. The versatile enclosures facilitate stacking, pole mounting and use in monitor position.
Specifications
System Type: Portable 2-way full-range loudspeakers with powered mixer
Maximum SPL Output: 121 dB peak
Frequency Range (-10 dB): 60 Hz - 20 kHz
Frequency Response (+/-3 dB): 70 Hz - 18 kHz
AC Input: 100-120 V, 220-240 V 50/60 Hz
Amp Design: Class D
System Power Rating: 300 W (2x 150 W stereo)
Output Connector: 2 x 1/4" TS (unbalanced) amplifier outputs
Channels
1-4: XLR/1/4" jack combo connectors
5-6: one pair of 1/4" balanced TRS jacks (stereo), and one pair of RCA jacks (stereo)
7-8: one pair of 1/4" balanced TRS jacks (stereo), and a 3.5mm stereo jack
Phantom Power: CH1 and CH2 have phantom power control and share the same selection switch
Hi-Z Selection: CH3 has a Hi-Z selection switch used for guitar signal input
Mixer Output Connectors: Monitor Out: one pair of RCA jacks (stereo), and one pair of 1/4" balanced TRS jacks (stereo)
Headphone Out: 3.5mm stereo jack
Subwoofer Out: 1/4" balanced TRS jack
Treble/Bass EQ: Per-channel high- and low-shelf filters; +/- 12dB cut and boost
System Limiter: On-board DSP limiting
LF Driver: 1x JBL 8" (203mm) woofer
HF Driver: 1x 1" Neodymuim black aluminum dome tweeter
Coverage Pattern: 100° horizontal x 60° vertical
Crossover Frequency: 2 kHz
Crossover Type: 2-way passive network, 2nd order filters (12dB cutoff per octave)
Enclosure: Polypropylene
Suspension/Mounting: 36 mm pole socket
Handles: One on top
Speaker Grille: Powder-coated perforated steel
Shipping Package (HxWxD): 22.6" (575 mm) x 30.5" (775 mm) x 15.7" (400 mm)
Net Weight: 38.8 lbs (17.6 kg)
