Description
Pre-Install In-Ceiling Backcan
The MTC-81BB8 is designed for use in applications requiring preinstalled backcans and is compatible with ceiling speakers having a 286 mm (11.25 in) mounting circle diameter, such as the JBL 8138 ceiling loudspeaker, and the JBL MTC-81TB8 tile bridge for suspended ceilings.
Features
- Fits 8138 speaker and MTC-81TB8 Tile Bridge
- Extra-large 7.4 liter (0.26 cu ft) volume allows for extra bass
- Industry standard 286 mm (11.25 in) mounting circle
- Five conduit knockouts
- Nesting during storage minimizes storage space requirements
- 4-Pack
Specifications
Internal Volume: 7.4 liters (0.26 cu ft)
Knockouts: 22 mm (0.87 in) diameter opening
Five (5) locations: 4 on side of can; 1 on top of panel of can
Suspension Tabs: 2 flexible perforated mounting straps, one on each side.
Attachment Points: 4 clip-nuts on 286 mm (11.25 in) mounting circle fix M4 tapping screws for attaching tile bridge to backcan, plus 4 thru holes providing clearance for screws from speaker to attach to tile bridge (see assembly drawing).
Material: 16 gauge (1.3 mm thick) steel, finished in black polymer E-coating for a high level of rust resistance.
Dimensions (H x W x D): 178 mm (7 in) height x 300 mm (11.75 in) width and depth
Net Weight (ea): 1.1 kg (2.5 lbs)
Shipping Weight (ea): 1.5 kg (3.2 lbs)
Associated Models: 8138 200 mm (8 in) ceiling speaker
MTC-81TB8 tile bridge for 600 mm (24 in) ceiling tile applications.
