Description
MAUI® 11 G3 SUB
Powered 2 x 8" Subwoofer for MAUI 11 G3
- Powered 2 x 8" subwoofer with flow-optimised bass-reflex ports
- 2 x 8" custom-designed woofer with deep bass down to 39 Hz
- Preset for cardioid subwoofer configuration
- DynX® DSP (Gen. 2) technology for distortion-free sound at maximum volume
- Automatic Setup Detection (MAIN / FOLLOWER)
- Rugged subwoofer housing made out of polyurea-coated birch plywood
- Shockproof front grille for ultimate speaker protection
- Two ergonomic handles for easy handling
Crisper and more powerful bass with additional LD MAUI 11 G3 SUB subwoofer.
With the MAUI 11 G3 SUB subwoofer, you extend the cardioid characteristics of our professional column speaker series right into the bass range.
What does this mean?
Simply position the SUB next to your MAUI® 11 G3 facing the rear direction, switch on the Cardioid preset and you will have a quieter and controlled Low-End on the back while still keeping the punch on the front. Low-End frequencies on the back of the system will be dampened by -15 dB. For extra Bass, keep the SUB in the same direction as your MAUI® 11 G3 and switch off the Cardioid preset.
Setting up the SUB with your MAUI® 11 G3 is straight forward and fast. Thanks to its automatic set-up detection system the SUB immediately switches to FOLLOWER mode as long as no column is attached.
Also recommendable is the protection cover and castor board to make transportation easy and keep the SUB as long as possible free of any touring-damage.
The MAUI® 11 G3 SUB features the same design construction as the MAUI® 11 G3 subwoofer and will be the perfect addition to get your Low-End in control.
Specifications
General
- Product type PA subwoofer
- Type Subwoofer
- Color Black
- Max. SPL (Peak) 125 dB
- Frequency response (-10dB) 39 Hz - 200 Hz
- Weight 20,5 kg
- Features Bluetooth Audio Streaming, DSP-based Signal Processing, Excellent Sound Dispersion, Mono/ Stereo Application
Subwoofer
- Woofer dimensions 2 x 8 "
- Woofer dimensions (mm) 2 x 203 mm
- Woofer magnet Ferrite
- Woofer brand Custom-made
- Woofer voice coil 2 "
- Woofer voice coil (mm) 50.8 mm
- Cabinet construction Bass Reflex
- Housing material 15 mm Multiplex
- Cabinet surface Polyurea
- Dimensions Subwoofer (W x H x D) 305 x 607 x 403 mm
- Subwoofer weight 20.5 kg
Amplifier module (integrated in subwoofer)
- Amplifier Class D
- System output (RMS) 730 W
- System output (Peak) 1460 W
- Protection circuits DC protection, Multiband limiter, Short circuit, Thermal protection
- Cooling Convection
- Controls Bluetooth, Cardioid On/Off, Main level, Power On/Off, Sub level
- Indicators Bluetooth, Cardioid On/Off, Follower mode, Power, Protect (protection circuit engaged), Signal, Subwoofer Mode
- Mains connector IEC power cable (included)
- Operating voltage 100 V AC - 120 V AC, 50 - 60 Hz, 220 V AC - 240 V AC, 50-60 Hz
- Fuse T 3.15AL / 250 V
- Power consumption 300 W
- Ambient temperature (operating) 0 - 40 °C
- Relative Humidity < 80% (non-condensing)
- Line Inputs 2
- Line Input Connectors Combo XLR / TRS
- Line Outputs 1 x Sub OUT, 2 x THRU
- Line Output Connectors XLR male
- Number of speaker outputs 1
- Loudspeaker Output Connectors Custom-made multipin
- Bluetooth Standard A2DP
- Bluetooth Audio Decoder AAC, SBC
DSP characteristics
- Bit depth AD/DA converter 24 bit
- Sampling frequency 48 kHz
