Description
U305.1 R
Receiver (USA version)
The U300®-series 12-channel UHF receiver operates with FM technology in the frequency band 514–542 MHz, and features a 25 Hz to 16 KHz frequency response. Convenient one-touch synchronisation via infrared ensures fast, problem-free wireless connection with the handheld transmitter microphone or bodypack from the same series. A squelch with pilot tone ensures disruption-free operation. The U3051 receiver features elegant metal housing with a bright LCD channel display, channel selection keys and LEDs that display audio signal strength and active antenna. The rear side features both a balanced XLR and unbalanced 6.35 mm audio output that is switchable to instrument level for directly connecting to guitar and bass guitar amps. Includes a power adapter and balanced XLR cable.
Specifications
- Product type Wireless Microphone System Accessories
- Type Receivers
- Modulation Type FM
- Transmission frequency range 514 - 542 MHz
- Channels 12
- Groups 1
- Antenna inputs 2 x fixed
- Frequency response 25 - 16.000
- Noise reduction Squelch
- Transmission optimization Pilot tone
- Total Harmonic Distortion (THD) < 0.3 %
- Signal-to-noise ratio 104 dB
- Audio output, balanced XLR
- Audio output, unbalanced 6.3 mm jack, switchable unbalanced output level
- Audio mix output, balanced XLR
- Audio mix output, unbalanced 6.3 mm jack
- Max. output level +10 dBu (Bal), +7 dBV (Unbal, Line), +2,5 dBV (Unbal, Instr) dBu
- Headphones outputs 6.3 mm TRS
- Controls ASC Sync, Channel down, Channel up, Line/Instrument Level, Power, volume
- Indicators 5 LED VU meters, Antenna A/B, LC display
- Power supply 12 V DC - 18 V DC (500 mA), external power supply
- Width 211 mm
- Height 43 mm
- Depth 120 mm
- Weight 0,7 kg
- Accessories (included) 2 x AA batteries, Audio cable, Power supply
- Other features IR frequency synchronisation
