Description
MA-50 Large-diaphragm Transformerless Condenser Microphone
The challenge? Create a transformerless microphone circuit without the inherent problems found in transformerless microphones. Technical Grammy® award winning microphone designer David Royer has created a thoroughly modern microphone that rises to that challenge: the new MA-50. Designed to produce the clarity and realism that Mojave microphones are known for – at an entry level price - the MA-50 out performs well-known transformerless mics costing many times more.
The MA-50 is the perfect microphone for pros and semi-pros alike. Utilizing the same capsule as the MA-200 and MA-201fet, it handles the fastest transients with ease – even up to 140 dB.
Features
• Large-diaphragm cardioid 3-micron capsule
• Fixed-cardioid polar pattern
• Transformerless circuitry
• Very low noise
• Includes professional shock mount
• Simple – yet elegant design - perfect for home recording
• High SPL handling
• Fast transient response
Recommended Applications
• Vocals
• Voice-over
• Acoustic Instruments
• Drum Overheads
• Percussion Instruments
• Foley/ADR
Specifications
- TRANSDUCER TYPE: Externally polarized pressure gradient capacitor
- DIAPHRAGM: 1-inch diameter, gold sputtered
- DIAPHRAGM THICKNESS: 3-microns
- POLAR PATTERN: Cardioid
- FREQUENCY RESPONSE: 20 Hz- 20 kHz, + 3 dB
- SENSITIVITY: -40 dB re. 1V/pa
- MAXIMUM SPL: 125 dB
- DISTORTION: <0.5% @140 dB SPL
- SELF NOISE: Better than 16 dB (A weighted)
- IMPEDANCE: <100 ohms
- RECOMMENDED LOAD: 1500 ohms or higher
- POWERING: 48VDC phantom power; current 2 mA.
- DIMENSIONS AND WEIGHT:
- Carrying case with microphone, shock mount: 10” x 9” x 4.5”, 4 lbs.
- Microphone: 7 5/8” X 2” (194mm x 51mm), 1 lb. (0.45Kg
