Description
The TF-5 represent a new standard in small diaphragm condensers. The all-new capsule is engineered to sub-micron tolerances, giving unprecedented consistency of tone and response.
The TF-5 features the hallmark clarity and airiness of other RØDE small diaphragm mics, and adds to this a unique warmth of tone which is often lacking in smaller ‘pencil mics’ of this type, making the TF-5 uniquely versatile.
Features
- Precision-paired small diaphragm cardioid condenser microphones
- Ultra-low noise
- Flat frequency response
- Tight cardioid directivity
- Warm, accurate sound
- Suitable for the most critical recording applications
- Designed in collaboration with Grammy® award winning classical producer and engineer, Tony Faulkner
Specifications
ACOUSTIC & ELECTRICAL SPECIFICATIONS
- Acoustic Principle Externally biased condenser
- Active Electronics JFET impedance converter with bipolar output buffer
- Polar Pattern Cardioid
- Frequency Range 20Hz - 20kHz
- Frequency Response 30 Hz - 20 kHz ±3dB // 20 Hz - 20 kHz ±4dB
- Output Impedance 63Ω
- Signal to noise Ratio 80 dB
- Equivalent Noise 14 dB SPL (A-weighted, as per IEC651)
- Input SPL @ 1% THD 135 dB SPL (1kHz @ 1% THD, 600Ω load)
- Sensitivity -29 dB re.1 Volt/Pascal or better (35 mV @ 94dB SPL @ 1kHz)
- Dynamic Range 112.6 dB (1kHz @ Max SPL)
- Power Requirements 7mA @ 48V phantom power
MECHANICAL SPECIFICATIONS
- Weight (g) 114g (single microphone)
- Dimensions Length: 98.7mm Diameter: 20mm
