Description
PM60 Personal Monitor Mic Preamp
The Rolls PM60 is an all in one Personal Monitor headphone amp with a fully functional Microphone Preamp built in. Now there is a way to have a personal monitor without the need for a dedicated mixer board with a mic preamp and microphone phantom power. The PM60 has all those features built in. The PM60 has many uses other than personal monitoring, it can be used as a stand-alone mic preamp with headphone monitoring, it can be used as a mic monitoring headphone amp for direct recording, and it can also be used as a two channel mixer with stereo line 1/4" or 1/8" out. It is perfect for podcasting, home recording, mixing, boom mic monitoring for camera recording and mixing, or as a stand-alone personal monitor. The PM60 is an all in one unit that has many capabilities. Made in the USA, with an all steel chassis, the PM60 is built to last.
Features
- 1/4" and 1/8" Headphone Outputs
- Ground Lift on XLR Mic
- Mono or Stereo 1/4" or 1/8" Monitor Input
- Individual Level controls
- Included PS27s power supply
Specifications
- Gain: 10dB 1/4" or 1/8", 48 dB XLR "mic"
- Input Impedance: 600 Ohms XLR, 22K 1/4” or 1/8” line
- Output Impedance: 10 Ohms Headphone
- Frequency Response: 3Hz to 100kHz
- THD: .05% @ 1kHz
- S/N Ratio: 90 dB
- PWR: 9-15 VDC
- Size: 4” x 3.25” x 1.6”
- Weight: 1.1 lbs
- Indicator: 1 Power LED
