Description
The durable BLX88 offers simple setup, intuitive controls, and microprocessor-controlled internal antenna diversity. One-touch QuickScan frequency selection quickly locates the best open frequency in case of interference. For use with BLX Wireless Systems.
Features
- XLR and ¼" output connectors
- Microprocessor-controlled internal antenna diversity
- Two-color audio status indicator LED
- Green: Normal audio levels
- Red: Excessive audio levels (overload / clipping)
Specifications
- Output Impedance
- XLR connector 200 Ω
- 6.35 mm (1/4") connector 50 Ω
- Audio Output Level
Ref. ±33 kHz deviation with 1 kHz tone - XLR connector –27 dBV (into 100 kΩ load)
- 6.35 mm (1/4") connector –13 dBV (into 100 kΩ load)
- RF Sensitivity -105 dBm for 12 dB SINAD, typical
- Image Rejection >50 dB, typical
- Dimensions 40 mm X 388 mm X 116 mm (H x W x D)
- Weight 429 g (15.1 oz.)
- Housing Molded ABS
- Power Requirements 12–15 V DC @ 160 mA (BLX88, 320 mA), supplied by external power supply (tip positive)
