Shure P9T - PSM 900 Wireless Transmitter

(No reviews yet) Write a Review
SKU:
P9T=-G6
UPC:
042406170154
Weight:
7.60 LBS
Shipping:
Calculated at Checkout
Availability:
Usually ships within 24 hours.
$734.00

Description

The P9T is a half-rack wireless transmitter used in conjunction with the P9R Bodypack receiver as part of the PSM®900 Wireless Personal Monitor System.

It offers state-of-art technology like CueMode (patent pending), Scan and Sync, and RF mute switch for easy setup and operation.

Connections include balanced 1/4” and XLR, loop out, and headphone out. Includes rack-mounting kit, front or back mountable antennas, and power supply.

Features

  • RF Mute Switch allows system setup without causing RF interference
  • Syncs to a P9R bodypack quickly and easily over IR link using Scan and Sync
  • Front panel audio input gain adjustment and LED level meter with clipping indicator
  • Front or back mountable antennas
  • Compatible with PA421A and PA821A antenna combiners
  • Loop out connectors for multiple mix setups and easy installation
  • Switchable +4 dBu and -10 dBV input level
  • Balanced, 1/4” and XLR connectors
  • Bit-mapped, backlit LCD
  • Includes rack-mounting hardware
  • 1/8” headphone out on the front panel for easy monitoring

Note: When purchasing separate wireless components, please match their frequency bands to ensure proper system operation.

View AllClose

Specifications

  • RF Output Power Selectable: 10, 50, 100 mW (regionally dependent)
  • RF Output Impedance 50 Ω (typical)
  • Net Weight 850 g
  • Dimensions 197 mm x 166 mm x 42 mm (7.75in X 6.55in X 1.65in)
  • Power Requirement 415 mA typical @ 120VAC (with RF on 100 mW power mode, no audio)
  • Audio Input
    • Connector Type: Combination XLR and 6.35 mm (1/4”) TRS
  • Polarity
    • XLR: Non-inverting (pin 2 positive with respect to pin 3)
    • 6.35 mm (1/4”) TRS: Tip positive with respect to ring
  • Configuration Electronically balanced
  • Impedance 70.2 kΩ (actual)
  • Nominal Input Level Switchable: +4 dBu, –10 dBV
  • Maximum Input Level
    • +4 dBu: +23.3 dBu
    • –10 dBV: +12.5 dBu
  • Pin Assignments
    • XLR: 1=ground, 2=hot, 3=cold
    • 6.35 mm (1/4”) TRS: Tip=hot, Ring=cold, Sleeve=ground
  • Phantom Power Protection up to 60 V DC
  • Audio Output
    • Connector Type 6.35 mm (1/4”) TRS
  • Configuration Electronically balanced
  • Impedance Connected directly to inputs
