Description
The PGA181 is a professional quality instrument microphone with an updated industrial design that features a black metallic finish and grille offering an unobtrusive visual presence. Legendary Shure quality construction ensures exceptional performance in rigorous environments.
Additional features include a tailored microphone cartridge design for smooth and versatile reproduction of sound sources.
Specifications
- Type Electret condenser
- Frequency Response 50 to 20,000 Hz
- Polar Pattern Cardioid
- Output Impedance 120 Ω
- Sensitivity
at 1 kHz, open circuit voltage - -38 dBV/Pa (12.7 mV)
1 Pa=94 dB SPL - Maximum SPL: 1 kHz at 1% THD, 1 kΩ 138 dB SPL
- Polarity Positive pressure on diaphragm produces positive voltage on pin 2 with respect to pin 3
- Weight 383 g (13.5 oz.)
- Connector Three-pin professional audio (XLR), male
- Housing Cast zinc
- Power Requirements 48 VDC phantom power (4 mA)
