Description
The UA834 provides more flexibility in wireless installations by increasing the allowable length of cable runs between a receiver and antenna. Antennas may be placed closer to the stage, or installed on ceilings and walls that maintain a better line of sight with the transmitter.
Features
- Two-position gain selector switch +6 and +12 dB
- Overload LED indication
- Low-noise signal amplifier compensates for insertion loss in coaxial cable
- Compatible with Shure Wireless Systems. Also may be used with Shure UA845 and UA844 Antenna Distribution Systems
- Integrated threaded adapter mounts easily to microphone stands or the supplied surface-mount bracket
- Shure quality, ruggedness, and reliability
Specifications
- Connector Type: BNC, Female
- Impedance: 50 Ω
- Power Requirements: 10 to 15 V DC bias from coaxial connection, 0.60–0.72 W
- Signal Gain, ±2 dB, Switchable: +6 dB +12 dB
- Absolute Maximum RF Input: +5 dBm
- RF Overload LED Threshold, ±2 dB: -5 dBm
- Input Third-Order Intercept Point (IIP3): >10 dBm
- Housing: Cast Aluminum, black painted finish
- Dimensions: 67 x 32 x 112 mm (H x W x D) Dimensions with Stand: 108 x 32 x 112 mm
- Net Weight
- Without Mounting Stand 0.28 kg (9.8 oz.)
- With Mounting Stand 0.42 kg (14.8 oz.)
