Solid State Logic ORIGIN Analog In-Line Console

Special Financing Available: Qualified borrowers are eligible for a special deal of $1095/month for 60 months through All Media Capital. Contact us for details!

This is our ORIGIN

As the latest in a long heritage of SSL studio mixing consoles, ORIGIN has traditional analogue studio workflow at its heart whilst providing the perfect partner for a modern DAW-driven hybrid production studio. ORIGIN takes a fresh look at what a large format console needs to do to work in harmony with a modern DAW driven production studio.

The functional design looks back at the origin of in-line consoles for signal flow inspiration, but its circuits are at the cutting edge of SSL’s latest analogue developments. These new analogue designs deliver huge dynamic range and bandwidth yet still have the characterful, pleasing qualities of space and depth that analogue breathes on digital audio.

Technical Innovation

ORIGIN is more than just the culmination of four decades of technical innovation. With our deep knowledge of workflow and studio integration, we understand that a console has to provide the immediacy and well-executed ergonomics that will inspire and engage a modern studio environment.

ORIGIN takes these principles and combines them with a modern feature-set that bridges the gap between digital production and analogue console workflow.

Analogue Layout Hybrid Workflow

A unique and innovative modular centre section allow ORIGIN to adapt to different applications and priorities, whether being used as a purely tracking console with additional boutique analogue additions to the 19” rack centre section, or a very digital/analogue hybrid approach with screens and controllers easily reached from the centre of the console.

E-Series '242' EQ

The E-Series '242' EQ was probably the most popular EQ from the SL 4000 series console range, and it's back for ORIGIN, which uses this iconic SSL design for it's channel EQ.

ORIGIN features the acclaimed E-Series four-band parametric EQ on each of its 32-channels, with variable Cut/Boost per band, HF and LF Bell/Shelf switches, independent sweepable HPF on every channel and unmistakable '242' style growl and deep low end.

PureDrive™

ORIGIN features a completely new microphone pre-amplifier design that inherits the clarity and purity of previous SSL mic pre's, with the added flexibility of switching character to a warm, harmonically-rich and driven tone that varies with gain. The ideal solution to 'perfect' digital system and hybrid workflow.

PureDrive™ is a new discrete transistor mic-pre based around modern FET components. The result is an ultra-clean, ultra-low noise pre amp, that is fast and offers stunning resolution when in 'Pure' mode. Hit the switch and the 'Drive' circuit is engaged, adding gain dependent non-linear harmonic saturation.

Key Features

• 32-channel analogue in-line design
• High quality 100mm large and 60mm small fader on every channel
• 16+2 buses
• 4x Monitor outputs
• 3x Foldback outputs
• Acclaimed SSL E-Series four band parametric channel EQ
• Sweepable HPF on every channel
• Classic SSL Bus Compressor with side-chain access, HP filter and insert point
• Dedicated channel direct outputs
• New PureDrive Mic pre & drive circuit
• New mix bus and mix amp architecture - delivers ultra-low noise floor and huge headroom
• Balanced Insert Point per Large Fader and Small Fader Channel Paths.
• Stem-ready 0dB fader bypass switch
• Unique power management tools deliver ultimate reliability and low running costs
• Freelance engineer friendly
• Adjustable centre section features 12U of rack space for:
• Software controllers
• Computer keyboard and accessories
• Additional hardware processing
• Drop down meter bridge

ORIGIN Centre Section

With the evolution of more sophisticated digital audio workstations and new hybrid approaches to session workflow, ORIGIN takes a fresh look at what an analogue console provides to complement these sophisticated digital tools.

While ORIGIN has a familiar surface, its design makes it adaptable for many different production scenarios. The 19” rack based ‘modular’ centre section allows the console to adapt to different control priorities and adds space for custom outboard processing. For example, the addition of a central 500 series rack provides a way to accommodate flexible analogue processing from a number of manufacturers, the ability to move the centre section allows for workstation controllers to be centrally located, even the 3U centre meter panel can be moved to allow a workstation monitor to move closer to the engineer without obscuring the main meters.

The sections below give an overview of possible centre section configurations.

Full Sized Keyboard

In this layout, the Centre Section has been moved towards the rear of the console by 3U.

A blank 3U panel has been moved into the space above the Stereo Group Faders and this can be used for a computer keyboard

DAW Controller Layout

This layout shows how the Centre Section can be moved to the top 6U of the console centre section.

The two 3U blank panels have been moved into the space above the Stereo Group Faders and this space is used for a DAW controller.

Alternate Meter Layout

ORIGIN's centre meters are built as a 3U panel, they can be moved into the upper 3U of the Centre Section.

In this image, the blank 3U panel is moved into the overbridge to keep the centre meters visible if the overbridge space is likely to be obscured (for example by a flat screen monitor / DAW screen)

Additional Hardware Processing

In this layout, the two 3U panels have been replaced with a 500 series rack fitted with 8 mono SSL Dynamics modules and a stereo SSL Bus Compressor.

A 1U grill panel has been fitted above the centre section to aid with ventilation and the remaining 2U fitted with a blank panel. The low right area next to the Stereo group faders has an Apple Magic trackpad placed on it.

The two 3U blanking panels have been moved into the space above the Stereo Group faders and this space s used for a DAW controller. The lower right area next to the Stereo group faders has an Apple Magic Trackpad.
