Description
The ultra-compact and lightweight 200-watt Traynor Small Block SB200H head is built for the travelling musician. At less than 7 ½ inches (20cm) wide and weighing under 1.5lbs (680g), the SB200H is small in stature, but big on tone. Loaded with essential features including Active and Passive level instrument inputs XLR DI output, a versatile four band EQ with an additional low frequency expander, the SB200H allows virtually any tone to be dialed in quickly and easily.
Designed to withstand the rigors of the road, the SB200H is built using an all-metal chassis with front mounted handles to protect the knobs and jacks. A combination Speakon™ – ¼-inch speaker output jack ensures the SB200H is included for maximum convenience. A ¼-inch Auxiliary Input allows source material to be blended with bass making the SB200H a perfect rehearsal tool. A ¼-inch headphone out is provided for private practice.
The SB200H is made in Canada and like all Traynor products, covered by our unconditional two-year transferable warranty.
Key Features
- Ultra Compact and Lightweight Design
- All-Metal Chassis
- Versatile 4-band EQ with Additional Low Frequency Expander
- Passive and Active Inputs
- Selectable Pre / Post XLR DI Output
- Auxiliary Input & Headphone Output for Private Practice
- Convenient Speakon™ – ¼-inch Combi-jack Speaker Output
- Made in Canada
Specifications
- Power @ min. impedance (Watts) 200 watts
- Minimum Impedance (Ohms) 4
- Burst Power – 2 cycle 250 watts
- Inputs Passive 0 dB, Active -6 dB
- Controls Gain, Bass, Low Mid, High Mid, Treble, Low Expander, Master Volume
- Additional Inputs ¼-inch Aux Input
- Line Out (type / configuration) Balanced Pre/Post Line Out W/ Ground Lift Switch
- Line Out Sensitivity (Vrms) 1 Vrms
- LED Indicators Blue – Power / Red – Protect/Mute
- Protection Clip, Thermal, Overcurrent
- External speaker output / location Speakon™ / ¼-inch Combi-Jack
- Other Features Aux Input /Headphone Out /Mute / Tuner Out
- Dimensions (DWH, inches) 7.5 x 8 x 1.75
- Dimensions (DWH, cm) 19.1 x 20.35 x 4.5
- Weight (lbs / kg) 1.5 / 0.68
- Specifications subject to change without notice
