Yorkville Passive Series PGM8 - Compact Mixer

(No reviews yet) Write a Review
SKU:
PGM8
UPC:
840402029939
Weight:
8.50 LBS
Shipping:
Calculated at Checkout
  • Yorkville Passive Series PGM8 - Compact Mixer
  • Yorkville Passive Series PGM8 - Compact Mixer
$439.00

Description

Passive Series - PGM8
Compact Mixer

The Yorkville PGM8 delivers all of the essential features needed in a professional mixer in a convenient, ultra-compact package. High quality 60mm faders throughout, effective fully featured input channel design, 24-bit digital effects, and break switch make the PGM8 the perfect mixer for live music applications and for small installs.

Features

  • Four Mono Input Channels with XLR & ¼-inch TRS inputs
  • Channel 4 Mono Input has a Hi-Z input switch
  • Two Additional stereo line input channels (5/6 and 7/8)
  • Additional XLR mono input per stereo channel for maximum 6 Mic inputs
  • Input gain level control with Non-defeatable soft multi-slope compressor on every input
  • 3-band EQ, High Pass Filter, Monitor send , Effect Send, Clip LED, Mute Switch and Pan control per Channel
  • 60mm Faders Throughout
  • Global 48 volt Phantom Power
  • 7-band stereo graphic EQ on Main Outs
  • Stereo RCA Record Outputs with Level Control
  • BREAK Switch (mutes all input channels)
  • Stereo RCA Media Input Jacks with Rotary Level Control (returns pre equalizer, post BREAK switch).
  • Monitor TRS Output
  • Main stereo TRS phone and XLR outputs
  • Sixteen 24-bit digital audio effects
  • Effects TRS output jack
  • Effects defeat footswitch jack
  • Effects return to Main and Monitor
  • Stereo Return TRS jacks with fader
  • Headphone Level Control
  • Stereo Headphone Output Jack (Signal strong enough to drive 8-ohm speakers)
  • Dual 10-segment LED Output Meter
  • IEC removable line cord receptacle (No Adaptors)
  • Universal Power Supply from 90VAC to 264VAC at either 50Hz or 60Hz.
View AllClose

Specifications

  • Number of Channels 8
  • Mono Channel EQ 3-band
  • Balance Controls Yes
  • Pan Controls Yes
  • Channel Overload Protection Yes
  • Inputs - XLR (bal) 6
  • Inputs - 1/4" 6
  • Inputs - RCA (unbal) 1 stereo pair
  • Phantom Power 48 volt + LED indicator
  • VU Meter 2 x 10 Segment LEDs
  • Headphone Monitor Features yes
  • Internal Effects 24 bit stereo 16 effects
  • Effects Send 2 (1 internal, 1 external)
  • Effects Return to Main Yes
  • Effects Return to Monitor Yes
  • Reverb / Effects Footswitch Yes
  • Record Outputs 1 stereo pair
  • Mixer - Signal to Noise Ratio (dB) Greater Than -100dB
    • 20Hz - 20KHz
  • Mixer THD (Main out w/ -10dB input) Less Than 0.05%
  • Typical crosstalk -1 kHz (dB- Greater Than -60dB
  • CMRR @ 60Hz (min/typ) 55dB/65dB
  • Power Consumption (typ/max) 26VA (typical)
  • Chassis Construction Steel
  • Dimensions (DWH, inches) 14.2 x 12.8 x 2.8
  • Dimensions (DWH, cm) 36 x 32.5 x 7
  • Weight (lbs/kg) 8.5/3.8
