Description
No more cables
For houses of worship, hotels, clubs and band applications.
The SR45 analog high-performance space diversity wireless receiver provides maximum ease of use with different channel presets up to eight channels. It is perfect for instrumental and vocal performances in small clubs as well as for use in houses of worship and in conference rooms.
The SR45 provides an audio clipping and RF signal LED for easy monitoring of systems status. Best audio signal output is provided via both a professional XLR and a 1/4" jack connector. For worldwide use, the receiver comes with a universal, switched mode power supply kit.
Features:
- 30MHz selection bandwidth - simultaneous use of up to 6 channels
- Professional balanced XLR and ¼" jack output - for best audio signal
- Audio clip and RF control LED on receiver - for easy monitoring of your performance
- Switched mode power supply - universal connector kit for worldwide use
- Adjustable squelch level - for secure audio transmission in all environments
Specifications
Audio
Audio frequency bandwidth: 40 to 20000 Hz
Signal to Noise: 105 dB-A
THD at 1 kHz: 0.8 Prozent
Miscellaneous
Operating temperature range: -10 to 55 Celsius
Radio Sensitivity: -100 dBm
Radio
Switching bandwidth: 30 MHz
Recommended simultaneous channels: 5
Number of selectable frequencies: 8 Fixed frequencies
Frequency Selection: Fixed frequency
Wireless channels within device -
Radio range (Line of sight): 30m
Switchable RF power: no
Modulation: FM
Encryption: No encryption
Pilot Tone: no
General
Transmitter Synchronization: Manual
HiQnet compatible: No
Racksize: 1/2 Racksize (19")
Rackheight: 1 RU
Audio Outputs: 1
Amount: 1
Type: Balanced XLR
Gender: Male
Contacts: 3-pin
Note: Balanced audio output adjustable from mic to line level.
Output level at rated deviation: 500 mV rms
Audio Outputs: 2
Amount: 1
Type: Jack Mono (1/4")
Contacts: 3-pin
Note: Unbalanced audio output
Powering Interface
Internal Power Supply: no
Type: DC Socket
Voltage: 12 to 12 V
Design
Body: Plastic
Finish: black
Dimensions / Weight
Length: 150 mm
Height: 44 mm
Width: 200 mm
