Description
The Antari AF-3™ is a mini but all-purpose stage fan with features 4 control options linear output control, low power consumption, adjustable output directions and a durable road worthy metal housing in a compact package. With on board DMX control and manual knob control as standard as well as wireless and wired remote control options. Low power consumption is only 100W allowing you to put on the same circuit as your fog machine. The adjustable mounting / floor bracket included allows you to adjust the fan output 90 degrees.
Features
Available Models:
- US model : AC 100-120V (ANF167)
- EU model : AC 220-240V (AF-3 240V)
Specifications
Input voltage
- US model : AC 100-120V, 50/60Hz 1A
- EU model : AC 220-240V, 50/60Hz 0.5A
Rated power
- 120W
Ambient temp. range
- 0 °C - 40 °C (32 °F-104 °F)
Air flow
- 900 m³/hr, 530 CFM (50Hz)
- 1020 m³/hr, 600 CFM (60Hz)
Fan speed
- 750 – 2550 rpm (50Hz)
- 750 – 2800 rpm (60Hz)
Control
- DMX, Manual
- Wireless (Optional)
DMX channels
- 1 channel
Connection
- Neutrik Powercon (Power)
- XLR 5-pin (DMX)
Optional accessories
- WTR-10 Wireless Remote
- Z-3 Cable Remote
Dimension
- L124 W316 H368 mm
- (L4.88 W12.44 H14.49 inch)
Weight
- 6 kg (13.23 lbs)
