Antari AF-3X Mini All-Purpose Stage Fan w/ 4 Control Options

(No reviews yet) Write a Review
SKU:
AF-3X
UPC:
4719850651749
Weight:
17.00 LBS
Shipping:
Calculated at Checkout
Availability:
Usually ships within 24 hours
  • N
  • N
  • N
  • N
  • N
$499.00

Description

The Antari AF-3™ is a mini but all-purpose stage fan with features 4 control options linear output control, low power consumption, adjustable output directions and a durable road worthy metal housing in a compact package. With on board DMX control and manual knob control as standard as well as wireless and wired remote control options. Low power consumption is only 100W allowing you to put on the same circuit as your fog machine. The adjustable mounting / floor bracket included allows you to adjust the fan output 90 degrees.

Features

Available Models:

  • US model : AC 100-120V (ANF167)
  • EU model : AC 220-240V (AF-3 240V)



View AllClose

Specifications

Input voltage

  • US model : AC 100-120V, 50/60Hz 1A
  • EU model : AC 220-240V, 50/60Hz 0.5A

Rated power

  • 120W

Ambient temp. range

  • 0 °C - 40 °C (32 °F-104 °F)

Air flow

  • 900 m³/hr, 530 CFM (50Hz)
  • 1020 m³/hr, 600 CFM (60Hz)

Fan speed

  • 750 – 2550 rpm (50Hz)
  • 750 – 2800 rpm (60Hz)

Control

  • DMX, Manual
  • Wireless (Optional)

DMX channels

  • 1 channel

Connection

  • Neutrik Powercon (Power)
  • XLR 5-pin (DMX)

Optional accessories

  • WTR-10 Wireless Remote
  • Z-3 Cable Remote

Dimension

  • L124 W316 H368 mm
  • (L4.88 W12.44 H14.49 inch)

Weight

  • 6 kg (13.23 lbs)
View AllClose
