Description
Z-1020 Two-Way Fog Jet
Z-1020, the most powerful DMX-controlled vertical pure fog machine which stands differently from the other Z-Series. Its design is for special purposes and applications which you can‘t find in any fog machines available. It uses mirror-piping heater technology that supports advance features and high-throughout burst mode with its extreme low energy consumption.
The Z-1020 can be positioned on the ground to fog upward to have a column of fog effect or can be mounted on the wall to easily blend the surroundings with atmospheric effect. Or else can be used to fog in upright position. Other features include DMX on-board, built-in electronic low fluid detector. Light weight, sleek and compact design, easy installation and maintenance.
Z-1020 is perfect for theatrical and studio application, large halls, concerts, DJ touring and clubs.
Specifications
- Input voltage
- US model : AC 100-120V, 50/60HZ 9A
- EU model : AC 220-240V, 50/60Hz 4.5A
- Rated power 1000W
- Warm-up time 13 minutes (approx.)
- Fluid consumption 90 ml/min
- Fluid tank capacity 2.4 Liters (0.63 gallon)
- Compatible fluid
- Antari FLC Super Light Fog Fluid
- Antari FLR Light Fog Fluid
- Ambient temp.range 0°C – 40°C (32°F – 104°F)
- Output 5 meters height
- Control Manual, DMX512
- Timer (Optional)
- Wireless (Optional)
- DMX channels 1 channel
- Connection
- IEC (Power)
- XLR 3-pin (DMX)
- Optional accessories Z-40 Cable Timer Remote
- Z-50 Wireless Remote
- FX- 4 Flight case
- Dimension L 408 W 295 H 199 mm
- (L 16.06 W 11.61 H 7.83 inch)
- Weight 9.8 kg (21.61 lbs)
