64-CHANNEL DANTE®, HDX & THUNDERBOLT 3™ AUDIO INTERFACE WITH ONBOARD DSP

Galaxy 64 Synergy Core

64 Channels of Analog Audio. Dante & HDX Connectivity. One Device.

Galaxy 64 Synergy Core is a high-end recording system that connects your entire studio within a 2U rack space while providing high-fidelity audio and onboard effects processing for your most demanding projects. With Dante, HDX and Thunderbolt connectivity, the world’s first 64-channel AD/DA converter offers unbeatable flexibility when moving sound around your high-profile production facility, live stage, broadcast, or other enterprise applications.

INTEGRATION

More Streamlined Workflow, Less Clutter

The interface is designed to be the hub of your entire recording environment that eliminates the need for any expansion modules and cards, thus centralizing your entire setup. Switching from project to project is effortless with the fast recall of presets and adapting to different workflows is made easier by allowing you to address numerous applications using a single hardware frame.

CONNECTIVITY

World’s First 64-Channel AD/DA Converter
In 2U Rack Space

Galaxy 64 Synergy Core is the only interface to offer two Dante ports for audio networking, four HDX ports for a full array of 128 channels in Pro Tools as well as Thunderbolt connectivity. These features can be used simultaneously with multiple systems for easy adaptation to different workflows with preferred DAW applications. This is all made possible by utilizing our exclusive FPGA configuration and advanced digital routing.

Analog

• 8x DB25 line inputs
• (64 channels at 24-bit, 192kHz)
• 64 аnalog input channels over 8 DSUB-25 connectors with AC/DC coupling switch (TASCAM standard)
• 8x DB25 line outputs
• (64 channels at 24-bit, 192kHz)
• 64 analog output channels over 8 DC-coupled D-Sub 25 connectors (TASCAM standard);
• 1× Stereo headphone output
• (24-bit, 192kHz)
• Stereo TRS jack for headphone monitoring with a D/A converter providing 122dB of headroom.
• 1× Stereo monitor output pair
• (2 channels at 24-bit, 192kHz)
• L/R studio speaker outputs on 1/4-inch TRS connectors with a dedicated converter providing 130dB of headroom

Digital

• 2x DANTE® Ports
• (64 channels at 24-bit, 48kHz)
• Primary and Secondary Dante® connections on RJ 45 (Ethernet) ports. The number of input and output audio channels is sample rate-dependent.
• 4x HDX Ports
• (128 channels at 24-bit, 192kHz)
• Four HDX ports enable interfacing to two HDX cards simultaneously for a primary/secondary recording setup or a full array of 128 channels.
• 2x Thunderbolt 3™ Ports
• (64 channels at 24-bit, 192kHz)
• Two Thunderbolt 3 ports for PC/Mac connection. The left port enables USB-C connection to a secondary computer for remote control purposes.
• 2x Optical MADI Ports
• (64 channels at 24-bit, 48kHz)
• Should the need for more channels arise, use the MADI ports on optical SC connectors to daisy-chain with another audio interface.
• 2x AES/EBU Ports
• (2 channels at 24-bit, 192kHz)
• Two AES/EBU ports on XLR connectors for digital expansion to AD/DA converters or monitoring systems.
• 2x S/PDIF (input and output)
• (2 channels at 24-bit, 192kHz)
• Two S/PDIF ports RCA connectors for digital expansion to AD/DA converters or monitoring systems.

Clocking

• 1x Word clock input
• The word clock input allows you to sync Galaxy 64 Synergy Core’s internal clock to an external master clock or other converter.
• 6x Word clock outputs
• With the word clock outputs, you can distribute the internal clock signal across the rest of your digital gear.
• 2x Loop sync (input and output)
• Word clock distribution system for HD and HDX set-ups that eliminates sync repatching.
• 1x 10M atomic reference input
• An atomic input allows reference from the 10MX atomic clock or the 10M reference clock.

DANTE® AUDIO OVER IP
Build your Network

Dante is the number one audio over IP choice for installations, live events, production facilities, and any situation where large volumes of high-definition digital audio must be reliably transferred over long distances. Achieved using just an Ethernet port, Dante connection is preferred among other digital network standards, due to its easy configuration and variety of product support.

The configuration provides straightforward integration and reliable redundancy, with the secondary RJ-45 port serving as a backup 64-channel Dante route. Galaxy 64 Synergy Core allows extensive real-time backup and multi-level recording options throughout every production stage.

HDX CONNECTION
128 Channels in Pro Tools at 192kHz Sample Rate

The only interface to offer four HDX ports provides primary or secondary recording solution per card or a full array of 128 channels of recording split to two systems. What is especially impressive about our exclusive FPGA configuration is that it allows this channel count to be maintained at high sample rates such as 192kHz.

Unlike modular systems, all I/O is available at any time without the need to exchange boards or change setups. This is the easiest way to interface multiple Pro Tools sessions through several hosts.

SOUND
High-Fidelity Conversion

High-spec AD/DA converters provide low total harmonic distortion and signal-to-noise ratio for artifact-free recording sessions. The Galaxy 64 Synergy Core does not require external converters for monitoring because of the dedicated mastering-grade monitor converter. It facilitates audio reproduction with a wider soundstage for critical listening without coloration or signal degradation.

Industry-Leading Clocking Technology

Our proprietary 64-bit Acoustically Focused Clocking and Jitter Management algorithm ensure the kind of audio quality that sets apart the legendary Isochrone Trinity master clock. The Galaxy 64 Synergy Core delivers the same increased width, separation, and detail in your musical performances.

D/A STAGE DYNAMIC RANGE: 128 dB
A/D STAGE DYNAMIC RANGE: 121 dB
MONITOR CONVERTER DYNAMIC RANGE: 130 dB

EFFECTS PROCESSING
36 Real-Time Effects Included

Galaxy 64 Synergy Core includes a massive expandable library of 36 real-time effects. It is largely composed of software emulations of vintage analog gear found in world-renowned recording studios. The collection does not lack in variety – you can find rarities like a boutique autowah pedal from Finland, a Danish master-grade compressor or emulation of famous units like American-design EQs.

18 EQUALIZERS, 12 COMPRESSORS & LIMITERS, 2 PREAMPS & CHANNEL STRIPS, 1 REVERB, 1 DE-ESSER, 1 TREMOLO, 1 AUTOWAH PEDAL

Synergy Core is currently one of the fastest-growing real-time effects processing platforms in the pro audio industry. In short, the Antelope Audio Synergy Core technology is a combination of the best of FPGA and DSP processing, brought together to give you a powerful, yet simple to use effects platform. It allows you to:

• offload all processing to the interface thus saving your host computer CPU & memory
• load effects while tracking or mixing and process with imperceptible latency

CONTROL PANEL
Intuitive Control Over All Features

Take charge of each aspect of the unit’s functionalities with a convenient software Control Panel. It provides intuitive control of all settings, gain adjustments, real-time effects, metering, and presets. From the Control Panel you have immediate access to the flexible Routing Matrix and the low latency internal mixers. Every Galaxy 64 Synergy Core feature works seamlessly once you establish your Control Panel workflow.
